Required Tools Si50-402
50 Semi-Hermetic Single Screw Compressor Version IV
Jig (4)-2 [Handle Jig Set]
(Z0125)
Parts No.
Name
Handle
Stay (1)
Stay (2)
Disc
Straight pin
Material
STPG370E
SS400 or
SM400A
SS400 or
SM400A
SS400 or
SM400A
S45C
Remarks
20A, sch40
(t2. 9)
Refer next page
JIS B1354
Class A or equivalent
Refer next page
Applicable
model
ZH3_F
ZH3_G
ZH5_
ZH7_
ZH9_
307
287
333
321
371
160
140
185
170
220
