5
2. DESCRIPTION
The 3 in 1 digital multi-tester has been designed to combine the functions of Digital Multimeter,
Telephone Line Tester and Network Cable Tester.
o DC voltage measurement, 5 ranges from 200mV to 1000V
o AC voltage measurement, 5 ranges from 200mV to 700V
o DC/AC current measurement, 5 ranges from 200µA to 10A
o Resistance measurement, 7 ranges from 200Ω to 200MΩ
o Diode test
o Audible continuity test
o Battery test: 1.5/6/9V
o Telephone Line test (RJ11)
o Network Cable test (RJ45)
Names of components
1. RJ11 test jack
2. RJ45 test jack
3. Data hold key (only for multimeter)
4. AC/DC switch key
5. -8 input jacks
6. RJ45 jackRemote
7. Function/range select rotary switch
8. Cable test key/Resent
9. Backlight key
10. LCD display
