2 Fluke Corporation 113 Digital Multimeter
Fluke Corporation
PO Box 9090, Everett, WA USA 98206
Fluke Europe B.V.
PO Box 1186, 5602 BD
Eindhoven, The Netherlands
For more information call:
In the U.S.A. (800) 443-5853 or
Fax (425) 446-5116
In Europe/M-East/Africa (31 40) 2 675 200 or
Fax (31 40) 2 675 222
In Canada (800)-36-FLUKE or
Fax (905) 890-6866
From other countries +1 (425) 446-5500 or
Fax +1 (425) 446-5116
Web access: http://www.fluke.eu
©2008 Fluke Corporation. Specifications subject
to change without notice. Printed in U.S.A.
4/2008 Pub_ID: 11409-eng Rev. 01
Maximum voltage between any
terminal and earth ground
600 V
Display 3 3/4-digits, 6000 counts, updates 4/sec
Operating temperature -10 °C to 50 °C (14 °F to 122 °F)
Storage temperature -40 °C to 60 °C (-22 °F to 140 °F)
Temperature coefficient 0.1 x (specified accuracy)/°C (< 18 °C or > 28 °C)
Operating altitude 2,000 m
Storage altitude 10,000 m
Relative humidity 95 % to 30 °C
75 % to 40 °C
45 % to 50 °C
Battery type 9 Volt Alkaline, ANSI 1604A / IEC 6F22
Battery life Alkaline: 300 hours typical, without backlight
Shock 1 Meter drop per IEC 61010-1-2001
Vibration Per MIL-PRF-28800 for Class 2 instrument
Size (HxWxL) 167.1 mm X 85.1 mm X 46.0 mm (6.58 in X 3.35 in X 1.81 in)
Weight 13.0 oz (404 g)
Safety Complies with ANSI/ISA 82.02.01 (61010-1) 2004, CAN/CSA-C22.2 No
61010-1-04, UL 61010-1 (2004) and IEC/EN 61010-1 2nd Edition for
measurement Category III, 600 V, Pollution Degree 2, EMC EN61326-1
EMI regulations Complies with FCC Part 15, Class B
Fluke. Keeping your world
up and running.
®
Accuracy is specified for 1 year after calibration, at operating temperatures of 18 °C to 28 °C,
with relative humidity at 0 % to 95 %. Accuracy specifications are given as follows:
Note:
Specifications are subject to change without notice.
± ( [ % of reading ] + [ number of least significant digits ] )
Function Range Resolution Accuracy
DC, 45 to 500 Hz 500 Hz to 1 kHz
Chek
1,2
6.000 V
60.00 V
600.0 V
0.001 V
0.01 V
0.1 V
2.0 % + 3 4.0 % + 3
Function
Range Resolution Accuracy
3
2.000 V 0.001 V 2.0 % + 3
3
Beeper on < 20 Ω, off > 250 Ω; detects
opens or shorts of 500 µs or longer
Ω
3
600.0 Ω
6.000 kΩ
60.00 kΩ
0.1 Ω
0.001 kΩ
0.01 kΩ
0.9 % + 2
0.9 % + 1
0.9 % + 1
3
1000 nF
10.00 µF
100.0 µF
9999 µF
1 nF
0.01 µF
0.1 µF
1 µF
1.9 % + 2
1.9 % + 2
1.9 % + 2
100 µF - 1000 µF: 1.9 % + 2
> 1000 µF: 5 % + 20
Notes:
1
All Chek voltage ranges are specified from 60 counts to 100 % of range. Because inputs below 60 counts are not
specified, it is possible and normal for this and other true-rms meters to display non-zero readings when the test
leads are disconnected from a circuit or are shorted together.
2
Crest factor of ≤ 3 at 4000 counts, decreasing linearly to 1.5 at full scale.
3
After measuring voltage, a wait time of 1 minute is required to maintain accuracy of ohms, capacitance, diode test,
and continuity.
Ordering
information
Fluke 113 True RMS Multimeter
Included
Fluke 113 Digital Multimeter
TL75 Test Leads
One 9V Battery
Printed Users Manual
Function Input Impedance (Nominal)
Chek
~3 kΩ < 300 pF
Common Mode Rejection Ratio (1 kΩ Unbalanced)
> 60 dB at dc, 50 or 60 Hz
Open Circuit Test Voltage Full Scale Voltage
Ω
< 2.7 V dc < 0.7 V dc
< 2.7 V dc 2.000 V dc
Short Circuit Current
Ω
< 350 µA
< 1.0 mA
Specifications
