Accuracy specifications
2 Fluke Corporation 114 Electrical Multimeter
Fluke Corporation
PO Box 9090, Everett, WA USA 98206
Fluke Europe B.V.
PO Box 1186, 5602 BD
Eindhoven, The Netherlands
For more information call:
In the U.S.A. (800) 443-5853 or
Fax (425) 446-5116
In Europe/M-East/Africa (31 40) 2 675 200 or
Fax (31 40) 2 675 222
In Canada (800)-36-FLUKE or
Fax (905) 890-6866
From other countries +1 (425) 446-5500 or
Fax +1 (425) 446-5116
Web access: http://www.fluke.
©2006 Fluke Corporation. All rights reserved.
Printed in U.S.A. 8/2006
Fluke. Keeping your world
up and running.
Ordering Information
Fluke-114 Electrical Multimeter
Included
TL75 Test leads, holster, User’s manual
and 9 V battery (installed).
Measurement Range Resolution Accuracy ± ([% of reading] + [counts])
DC millivolts 600.0 mV 0.1 mV 2.0 % + 3
DC volts 6.000 V 0.001 V
60.00 V 0.01 V
600.0 V 0.1 V
Auto volts 600.0 V 0.1 V 2.0 % + 3 (dc, 45 Hz to 500 Hz)
4.0 % + 3 (500 Hz to 1 kHz)
AC millivolts
1
true-rms 600.0 mV 0.1 mV 1.0 % + 3 (dc, 45 Hz to 500 Hz)
2.0 % + 3 (500 Hz to 1 kHz)
AC volts
1
true-rms 6.000 V 0.001 V
1.0 % + 3 (dc, 45 Hz to 500 Hz)
2.0 % + 3 (500 Hz to 1 kHz)
60.00 V 0.01 V
600.0 V 0.1 V
Continuity
600
W 1 W Beeper on < 20 W, off > 250 W; detects
opens or shorts of 500 µs or longer.
Ohms
600.0
W 0.1 W
0.9 % + 2
6.000 k
W 0.001 kW
0.9 % + 1
60.00 k
W 0.01 kW
600.0 k
W 0.1 kW
6.000 M
W 0.001 MW
40.00 M
W 0.01 MW
1.5 % + 2
Notes:
1
All ac voltage ranges are specified from 1 % to 100% of range. Because inputs below 1 % of range are not specified,
it is normal for this and other true-rms meters to display non-zero readings when the test leads are disconnected
from a circuit or are shorted together. For volts, crest factor of
≤ 3 at 4000 counts, decreasing linearly to 1.5 at full
scale. AC volts is ac-coupled. Auto-V LoZ, and ac mV are dc-coupled.
2
Frequency is ac coupled, 5 Hz to 50 kHz for ac voltage.
e
u
Pub_ID: 11156-eng
