2 Fluke Corporation Fluke Connect™ Modules
a3000 FC general specifications
Range 0.5 A to 400.0 A
Resolution 0.1A
Accuracy 400.0 A: 2% ± 5 digits (10Hz to 100Hz), 2.5% ± 5 digits
(100Hz to 500Hz)
Inrush Max displayed reading: 999.9A
Crest factor (50Hz/60Hz) 3 at 500A, 2.5 at 600A, 1.42 at 1000A, add 2% for C.F. > 2
LCD w/backlight 3½ digits
Log rate/interval 1 sec minimum/adjustable by PC
Battery type 2 AA, NEDA 15A, IEC LR6
Battery life 400 hours
Memory Record up to 65,000 readings
RF communications 2.4 GHZ ISM Band
RF communication range Open air, unobstructed: Up to 20 m
Obstructed, sheetrock wall: Up to 6.5 m
Obstructed, concrete wall or steel electrical enclosure: Up to 3.5 m
Operating temperature -10°C to +50°C
Storage temperature -40°C to +60°C
Temperature coefficient Add 0.1x (specified accuracy)/°C (< 18°C or > 28°C)
Operating humidity 90% at 35°C, 75% at 40°C, 45% at 50°C
Altitude Operating: 2,000 m
Storage: 12,000 m
EMC EN 61326-1:2006
Safety compliance IEC 61010-1, 600 V CAT III, 3rd edition Pollution Degree 2
Safety rating CAT III 600 V
Certifications CSA, CE, FCC: T68-FBLE IC: 6627A-FBLE
Ingress Protection (IP) rating IP30
Pollution Degree 2
Jaw opening 34 mm (1.33 in)
Size (HxWxD) 20.3 cm x 7.49 cm x 3.55 cm (8 in x 2.95 in x 1.4 in)
Weight .22 kg (8 oz)
(Not compatible with Fluke CNX test tools)
Fluke a3000 FC Wireless AC Current Clamp Module
A fully functional true-rms current clamp meter that wirelessly
relays measurements to other Fluke Connect™ enabled master units,
listed below.
• Fluke 3000 FC DMM
• Fluke Ti200/300/400 Infrared Camera
• PC via optional pc3000 FC Adapter
• Fluke Connect Mobile app
a3000 FC main features include:
• True-rms ac clamp meter
• Measure up to 400 A ac
• Use as a standalone meter or as part of the system
• Logging function for recording and saving up to 65,000 readings
• Inrush function
