MTX 3290- MTX 3291- MTX 3292 - MTX 3293
MEASUREMENTS
MEASUREMENTS
The TRMS measurements of AC voltages and currents are also accurate on non-linear signals.
Recording
Depending on the model, ASYC IV multimeters can record up to 6,500 values.
The simplified parameter settings concern the number of measurements,
the recording interval (1 s to 24 h), the duration and the storage capacity.
A broad measurement
range is provided for
capacitance measurements:
from 1 nF to 60 mF depending on the model.
CAPACITANCE
General configuration
and customization of the
measurement functions.
SETUP
Resistance can be
measured up to 100 MΩ.
A reminder of the
connections is constantly displayed
at the top of the display.
RESISTANCE
Continuity with audible beep
Voltage measurement can be
performed in total safety up to 1,000V.
AC, DC OR AC+DC VOLTAGE
The ASYC IV models
measure the frequency up
to 600 kHz (MTX3290 and MTX 3291) and up to
5 MHz with the 2 top-of-the-range models,
the MTX3292 and MTX 3293.
FREQUENCY
Depending on the models,
J/K thermocouples or
Pt100 / Pt1000 sensors
can be used to measure temperature.
TEMPERATURE
AC, DC and AC+DC current
measurement with direct
readings up to 10 A.
CURRENT
The ASYC IV multimeters offer
direct readings of current
measurements with a clamp,
which also extends the
measurement range up to 100A.
VOLTAGE
The mV/A or A/A ratio can be
set on the MTX3292/3293.
Fixed mV/A ratio on the MTX3290/3291
