METRIX MTX3290 [5/8] Functions
![METRIX MTX3291 [5/8] Functions](/views2/1664926/page5/bg5.png)
The capture of time/date-stamped minimum /
maximum / average and PEAK values makes
it possible to record the transient values
and variations automatically. This function enables effective
detection of a signal’s variations or anomalies.
Depending on the model, users can integrate the
transformation ratio for direct readings of the current value,
whether the clamp is equipped with a V or A output.
CONTROL OF MEASUREMENT
WITH THE SURV AND
PEAK FUNCTIONS
MEASUREMENT WITH CURRENT CLAMP
A 300 Hz low-pass filter ensures accurate voltage and
frequency measurements on the drive units of PWM
variable-speed motors.
ACCURATE MEASUREMENTS,
INCLUDING ON VARIABLE SPEED DRIVES
The “user/basic” function saves the preferred settings
when the instrument is powered down, on the basis of the
user’s preferences, so it is no longer necessary to repeat
the settings!
USER-FRIENDLY AND TIME-SAVING
Frequency can be measured up to 5 MHz. This function can
be used in addition to +/- duty cycle measurement to analyse
the active or inactive intervals of switching signals or logic
signals. PW+/- pulse width measurement allows you to
check electronic fuel injection systems and switching power
supplies.
Hz FUNCTIONS
The RANGE function allows you to select the most suitable
measurement range for the measurements in progress,
either automatically or manually.
FLEXIBILITY
The REL relative mode can be
used to express measurements
as absolute and relative
differences with regard to the
reference measured.
RELATIVE VALUES FOR
GREATER PRECISION
Main value + secondary values
with graphical trace.
RECORDING OF 6,500
MEASUREMENTS IN THE
MULTIMETER’S MEMORY
FUNCTIONS
This function is adapted for
the measurement of any
physical quantity by
appropriate unit conversion
and offers direct readings
(Ax+B).
MATH FUNCTION
Communication
The ASYC IV models are equipped with a universal communication
mode based on the SCPI standard, via USB or Bluetooth. The SX-DMM
software provides a simple and effective way of viewing, processing
and analysing the data, while also allowing real-time processing of
the data on a PC, upgrading of the instrument and even calibration
with new functions: automatic clock adjustment. It is also possible
to display the available storage capacity.
