![METRIX MTX3291 [7/8] Mtx 3292 mtx 3293](/views2/1664926/page7/bg7.png)
High-performance graphical multimeters…
• Easy-to-read 320 x 240-pixel colour matrix screen with black
background
• Graphical display of the trends on a summary screen
• Trace, cursors and zoom on recordings
• Recording of 10 sequences
Dynamic loggers
• Storage of up to 6,500 measurements
• Simplified setting of the number of measurements, interval,
duration and storage capacity
• Internal storage of measurement 10 sequences
• Interactive zoom function on the recordings
• A simple surveillance mode displaying the time/date-stamped
MIN/MAX and AVG values
... And much more!
• Contextual reminder of the connections
• Normal USB communication or Bluetooth available as an option
• IP67 protection against water projections and dust, ideal for
outdoor conditions
• Ni-MH AA rechargeable battery, the best solution in terms of
quality and price
• Operation for up to 100 hrs on batteries with management of the
battery charge level
• No time-wasting: the instrument operates while charging
MTX 3292 & MTX 3293
MTX 3290 MTX 3291 MTX 3292 MTX 3293
Display resolution (counts)
6 k
60 k 100 k 100 k
VAC/DC/AC+DC
•
• • •
VLowZ
•
• • •
IAC / I DC
•
• • •
IAC+DC
•
• • •
IAC/DC direct reading
•
• • •
Resistance
•
• • •
Capacitance
•
• • •
Frequency meter
•
• • •
Audible continuity / Diode test
• / •
• / • • / • • / •
Temperature with K TC / Pt100
- / •
- / • • / • • / •
dBm (/R) / dB (/Vref)
- / -
• / - • / • • / •
Resistive power
-
• • •
Duty cycle /
Pulse width /
Pulse counting
- / - / -
• / •/ - • / • / • • / • / •
HOLD / Auto- HOLD
• / •
• / • • / • • / •
Min / Max / Avg
• / • / •
• / • / • • / • / • • / • / •
Peak+ / Peak- / CF
• / •/ -
• / •/ - • / • / • • / • / •
Relative measurements
• • •
MATH function
-
- • •
Recording
-
- 1,000 6,500
USB communication / Bluetooth
-
• • / • (option) • / • (option)
CAT III / CAT IV
600 V / -
1,000 V / 600 V 1,000 V / 600 V 1,000 V / 600 V
3-year warranty
•
• • •
Type
Graphical
Models
MTX 3292 MTX 3293
Display
Graphical colour (70 x 52 mm)
Keypad
7 function keys + setup
Power supply
4 x R6 batteries or 4 rechargeable batteries
(internal charger)
Communication
IR/USB (Bluetooth as an option)
Storage
1,000 measurements 6,500 measurements
MTX 3293
MTX 3292
These portable multimeters with graphical colour display allow direct measurement of the main
electrical quantities and show the trends instantaneously. They benefit from an innovative design
making them compact, rugged, leakproof and comfortable to grip. Their strengths lie in the
productHMI, theadvanced measurement functions and the help provided when measuring.
