MTX 3290- MTX 3291- MTX 3292 - MTX 3293
MTX 3290 MTX 3291* MTX 3292 MTX 3293
DC, AC and AC+DC voltages
60 mV to 600 V 60 mV to 1,000 V 100 mV to 1,000 V
DC accuracy
0.3 % 0.05 % 0.03 % 0.02 %
AC and AC+DC bandwidth
20 kHz 100 kHz 100 kHz 200 kHz
DC, AC and AC+DC current
600 µA to 10 A /20 A (30 s max)* 1000 µA to 10 A /20 A (30 s max)
DC accuracy
0.08 % 0.01 %
Frequency
60 Hz to 600 kHz 10 Hz to 5 MHz
Resistance
600 Ω to 60 MΩ 100 Ω to 100 MΩ
Audible continuity
600 Ω SIGNAL < 30 Ω ±5 Ω < 5 V 1000 Ω SIGNAL < 20 Ω < 3,5 V
Diode test
3 V with 1 mV resolution Diode 0 -2.6 V < 1 mA + Zener Diode or LED 0-20 V < 11 mA
Capacitance
6 nF to 60 mF 1 nF to 10 mF
Temperature PT100/1000
-200 °C to 800 °C
Temperature TK/TJ
- -40 to +1,200 °C
OTHER FUNCTIONS
Surveillance
Time/date-stamped MAX/MIN /AVG or PEAK ±, on all the main positions SURV time/date-stamped MAX/MIN /AVG or PEAK ±, on all the main positions
REL
REL relative value + measured reference value on secondary display* Display of measured value and, on 3 secondary levels, the REF value,
the difference expressed in the measurement unit and the difference in %
PWM filter
4th-order 300 Hz low-pass filter for measuring on variable speed drives of asynchronous motors
V-output clamp function for
direct reading
Integration of the ratio: 1/1 ,1/10,1/100,1/1000 mV/A Parameterizable Ax ratio
Secondary functions or measurements
dBm and VA resistive power, +/- duty cycle, and pulse width* 3 measurements + main measurement
SPEC
- Display of measurement tolerance: Smin, Smax
GRAPH
- Trends of main measurements < 60 s + Zoom + Cursor
Central zero
Selectable or automatic* bargraph for VDC and IDC Automatic trend bargraph
Measurement storage
- 1,000 6,500
GENERAL SPECIFICATIONS
Type of display
LCD with backlighting* and digits 14 mm high – Double 60,000* or 6,000-count display Colour graphical display (70 x 52) with backlighting on 4 100,000-count displays
PC interfaces
- USB optical connector & SX-DMM software USB optical connector or Bluetooth (option)– SX-DMM software
Power supply
4 x AA batteries or Ni-MH batteries Charger or 4 x AA batteries or Ni-MH batteries
Safety / EMC
Safety as per IEC 61010-1 1,000 V-CAT III/600 V CAT IV* or 600 V CAT III /300 V CAT IV
Safety as per IEC 61010-2-033
Safety as per IEC 61010-1 1,000 V-CAT III /600 V CAT IV
Safety as per IEC 61010-2-033
Environment
Storage -20 °C to +70 °C – Operation -10 °C to +55 °C Storage: -20 °C to +70 °C – Operation: 0 °C to +40 °C
Mechanical specifications
Dimensions (L x P x H): 196 x 90 x 47.1 mm – Weight: 570 g
Warranty
3 years
STATE AT DELIVERY
• MTX 3290 delivered with 4 x 1.5 V alkaline batteries, 1 red straight/straight lead 1.5 m long, 1 black straight/straight lead 1.5 m long, 1 red CAT IV 1 kV test probe, 1 black CAT IV 1 kV test probe,
1 user’s manual on CD and 1 start-up guide on paper.
• MTX 3291 delivered with 4 x 1.5 V alkaline batteries, 1 red straight/straight lead 1.5 m long, 1 black straight/straight lead 1.5 m long, 1 red CAT IV 1 kV test probe, 1 black CAT IV 1 kV test probe,
1 user’s manual on CD and 1 start-up guide on paper plus 1 bag, 1 USB cable with SCPI remote programming manual and SX-DMM software.
• MTX 3292 and MTX 3293 delivered with 1 bag, 4 NI-MH 2,400 mAH 1.5 V rechargeable batteries, 1 charger, 1 red straight/straight lead 1.5 m long, 1 black straight/straight lead 1.5 m long,
1 red CAT IV 1 kV test probe, 1 black CAT IV 1 kV test probe, 1 optical USB cable + SX-DMM software, 1 user’s manual on CD and 1 SCPI remote programming manual and
1 start-up guide on paper.
REFERENCES
1 MTX 3290 multimeter ............................... MTX3290
1 MTX 3291 multimeter ............................... MTX3291
1 MTX 3292 multimeter ............................... MTX3292
1 MTX 3293 multimeter ............................... MTX3293
1 MTX 3292 multimeter - Bluetooth version....... MTX3292-BT
1 MTX 3293 multimeter - Bluetooth version....... MTX3293-BT
Information and ordering
FRANCE
Chauvin Arnoux
190, rue Championnet
75876 PARIS Cedex 18
Tel: +33 1 44 85 44 38
Fax: +33 1 46 27 95 59
export@chauvin-arnoux.fr
www.chauvin-arnoux.fr
MIDDLE EAST
Chauvin Arnoux Middle East
P.O. BOX 60-154
1241 2020 JAL EL DIB - LEBANON
Tel: +961 1 890 425
Fax: +961 1 890 424
camie@chauvin-arnoux.com
www.chauvin-arnoux.com
INTERNATIONAL
Chauvin Arnoux LTD
Unit 1 Nelson Ct, Flagship Sq, Shaw Cross Business Pk
Dewsbury, West Yorkshire - WF12 7TH
Tel: +44 1924 460 494
Fax: +44 1924 455 328
info@chauvin-arnoux.co.uk
www.chauvin-arnoux.com
906211429 - Ed. 3 - 06/2017 - Non-contractual document.
OPTIONS
MTX329X graphical colour calibration software ............................. HX0059B
MTX digital DMM transport kit .................................................. HX0052B
Graphical colour DMM transport kit ............................................ HX0052C
MTX 3290 / 3291 calibration software .......................................P01196770
Kit of 4 external Ni-MH rechargeable batteries .............................. HX0051B
MTX 328X and MTX 329X external battery charger (4 batteries incl.) .... HX0053B
