5.2. Using the stand

Use your meter’s stand to prop up the meter. If you prop your meter

on a bench-top, the stand helps provide a better viewing angle.

To use the stand as a prop, just open it away from the meter and

set it on a flat surface.

6. How to make measurements

Understanding Phantom readings:

In some DC and AC voltage ranges, when the test leads are not

connected to any circuit, the display might show a phantom reading.

This is normal. The meter’s high input sensitivity produces a

wandering effect. When you connect the test leads to a circuit,

accurate reading appear.

6.1. Measuring AC/DC voltage

WARNING!

Do not try to measure a voltage greater than 600 V DC or AC. You

might damage your meter and expose yourself to a severe shock

hazard.

Follow these steps to measure DC/AC Voltage.

1. Set the rotary selector to the desired position. Select the range

as required for the voltage level to be measured. If you do not

know the voltage level, start with the range switch set to the

highest voltage position and reduce the setting as needed to

get a reading.

2. Plug the black test lead into the meter’s COM terminal and the

red test lead into the V//Hz-terminal.

3. Connect the test leads to the DC/AC voltage source you want to

measure.

Warning! When you connect the test probes to an AC outlet, do not

turn the rotary selector switch to another range. It could damage the

meter’s internal components or injure you.
