Uni-T UT55 Расширенная инструкция онлайн
Contents
A Your Meters Feature
B Specifications
C Making Measurements
D Maintenance
E Accessories
F Using Holster
G Using Strap
Introduction
One kind of UNI-T brand new UT50 series
Multimeters is a 3 1/2 digit with steady function
and highly reliable hand-held measuring instrument.
The Meter uses large scale of integrated circuit
with double integrated A/D converter as its core
and has full range overload protection. The Meter
can measure DC current, AC current, DC Voltage,
AC Voltage, Resistance, Capacitance, Diode,
Temperature, Frequency and Continuity, which is
an ideal tool for users.
Model UT51-55: OPERATING MANUAL
1
Содержание
- The meter is suitable for indoor use only 3
- Accuracy is specified for one year after calibration 5
- At operating temperatures 23 5
- B 1direct current voltage dc voltage 5
- B 2 alternating current voltage ac voltage 5
- B specifications 5
- Frequency 40hz 400hz overload protection 200mv is 250vdc or ac rms all other ranges is 750vrms or 1000vp p display average value rms of sine wave 5
- Input impedance all ranges are 10 5
- Overload protection 200mv is 250vdc or ac rms all other ranges is 750vrms or 1000vp p 5
- With relative humidity at 75 accuracy specifications take the form of a readings digits 5
- B 5 resistance 8
- B 6 capacitance 8
- B 7 frequency 8
- Range as test lead is short circuit the lcd display 10 digits is normal deduct the 10 digits from the measured reading during measuring 8
- Range open circuit voltage around 3v overload protection all ranges 250vdc or ac rms caution at 200 8
- Testing signal around 400hz 40mvrms 8
- Voltage at open circuit 700mv 200 8
- B 10 transistor hfe test 9
- B 8 temperature 9
- B 9 diode test and continuity beeper 9
- Input sensitivity 100mvrms overload protection 250vrms 9
- Overload protection 250v dc or ac rms 9
- C making measurements 10
- Capacitance jack 10
- Input jack 10
- Liquid crystal display 10
- On off switch 10
- Rotary switch 10
- Temperature jack 10
- Transistor jack 10
- Please refer to dc current caution 1 2 3 12
- C 7 measuring frequency 14
- D maintenance i general service 15
