C. Making Measurements
“ ”
“ ”
1 On/Off Switch 2 Capacitance jack
3 Liquid Crystal Display 4 Temperature jack
5 Rotary switch 6 Transistor jack
7 Input jack
Model UT51-55: OPERATING MANUAL
