A. Your Meters Feature
l 32 ranges.
l Liquid Crystal Display, digits height is 27mm.
l Overload display l.
l Maximum display 1999 (3 1/2 digit).
l Full range overload protection.
l Auto-Power Off (For UT53, UT54 and UT55
ONLY).
l Temperature:
Operating:0
o
C to 40
o
C (32
0
F to 104
0
F).
Storing:-10
o
C to 50
o
C (14
0
F to 122
0
F ).
l Altitude:
Operating: 2000m
Storing: 10000m.
l Relative Humidity:Max. relative humidity
80% for temperature up to 31
o
C decreasing
linearly to 50% relative humidity at 40
o
C.
l Low Battery display " " .
l Strap for easy carry.
l Tilt stand design, three observation angles,
is in favor of reading display.
l Dimension: 190mm x 88mm x 34mm.
l Weight: Meter only(excluding test leads)
about 270g .Meter + holster + tilt stand
about 550g.
l Battery Type: 9V NEDA 1604 or 6F22 or 006P
Model UT51-55: OPERATING MANUAL
4
