Digital Multimeters
5490C Series
4
www.bkprecision.com
Specifications - 5492C / 5492CGPIB
Specifications are based on the following conditions:
- One year calibration cycle
- Calibration temperature T
CAL
= 23 °C
- Accuracy specifications: ± (% of reading + % of range), valid for T
CAL
±5 ºC
- For DC: The technical specifications are valid after a warm-up time of 60 minutes, with the integration time set to 10 or 100 NPLC, and auto zero enabled.
- For AC: The technical specifications are valid after a warm-up time of 60 minutes, slow AC filtering enabled, using a sine wave input signal.
Range
(1)
Resolution
Full Scale
Reading
Accuracy
(1 year)
100 mV 1 µV 119.999 mV 0.012 + 0.008
1 V 10 µV 1.19999 V 0.010 + 0.005
10 V 100 µV 11.9999 V 0.010 + 0.005
100 V 1 mV 119.999 V 0.010 + 0.005
1000 V 10 mV 1050.00 V 0.010 + 0.005
(1) 20% overrange on all ranges except 1000 V can only test 5% overrange.
DC Current
Range
Burden
Voltage
Resolution
Full Scale
Reading
Accuracy
(1 year)
100 µA < 0.011 V 1 nA 119.999 µA 0.050 + 0.008
1 mA < 0.11 V 10 nA 1.19999 mA 0.050 + 0.005
10 mA < 0.05 V 0.1 µA 11.9999 mA 0.050 + 0.008
100 mA < 0.5 V 1 µA 119.999 mA 0.050 + 0.005
1 A < 0.7 V 10 µA 1.19999 A 0.100 + 0.010
3 A < 2.0 V 10 µA 3.1500 A 0.150 + 0.020
10 A < 0.5 V 100 µA 11.9999 A 0.200 + 0.010
Range
(3)
Test Current Resolution Full Scale Reading Accuracy (1 year)
10 Ω 10 mA 0.1 mΩ 11.9999 Ω 0.050 + 0.008
100 Ω 10 mA 1 mΩ 119.999 Ω 0.040 + 0.005
1 kΩ 1 mA 10 mΩ 1.19999 kΩ 0.030 + 0.004
10 kΩ 100 µA 0.1 mΩ 11.9999 kΩ 0.030 + 0.004
100 kΩ
(4)
50 µA 1 Ω 119.999 kΩ 0.030 + 0.004
1 MΩ 5 µA 10 Ω 1.19999 MΩ 0.030 + 0.004
10 MΩ 500 nA 100 Ω 11.9999 MΩ 0.100 + 0.004
100 MΩ 500 nA || 10 MΩ 1 kΩ 119.999 MΩ 1.000 + 0.010
DC Resistance
(2)
(2) Specifications apply to 2-wire and 4-wire resistance measurements using NULL for offset. Without NULL, add 0.2 Ω additional error for 2-wire measurements.
(3) 20% overrange on all ranges
(4) To eliminate noise interference, it is recommended to use shielded test cables for resistance measurements above 100 kΩ.
DC Voltage
Range
(5)
Test Current
Full Scale
Reading
Accuracy
(1 year)
1 nF 10 µA 1.19999 nF 1.0 + 0.5
10 nF 10 µA 11.9999 nF 0.5 + 0.1
100 nF 10 µA 119.999 nF 0.5 + 0.1
1 µF 100 µA 1.19999 µF 0.5 + 0.1
10 µF 100 µA 11.9999 µF 0.5 + 0.1
100 µF 1 mA 119.999 µF 0.5 + 0.1
1 mF 10 mA 1.19999 mF 0.5 + 0.1
10 mF 10 mA 11.9999 mF 1.0 + 0.50
Capacitance
Frequency
Range
Resolution
Full Scale
Reading
Accuracy
(1 year)
3 Hz to 10 Hz 10 µHz 9.99999 Hz 0.050 + 50
10 Hz to 100 Hz 100 µHz 99.9999 Hz 0.010 + 10
100 Hz to 1 kHz 1 mHz 999.999 Hz 0.005 + 2
1 kHz to 10 kHz 10 mHz 9.99999 kHz 0.005 + 2
10 kHz to 100 kHz 0.1 Hz 99.9999 kHz 0.005 + 2
100 kHz to 300 kHz 1 Hz 300.000 kHz 0.005 + 2
300 kHz to 1 MHz
(8)
1 Hz 999.999 kHz 0.005 + 2
Frequency
(6)(7)
(6) Applies to sine wave input and gate time set to 1 second.
(7) For sine wave input larger than 100 mV. For a 10 mV to 100 mV input, multiply the
% of reading error by 10.
(8) For frequency measurements greater than 750 kHz, use manual ranges for best
accuracy.
(5) 20% overrange on all ranges.
