Digital Multimeters
5490C Series
9
www.bkprecision.com
v091420
General
AC Input 110 V/220 V ±10%, 50/60 Hz
Power Consumption ≤ 30 VA
I/O Interface RS232, USB host, USB (USBTMC-compliant) device, LAN, GPIB (5492CGPIB and 5493CGPIB only)
Temperature
Operating 32 °F to 104 °F (0 °C to 40 °C)
Storage -40 ºF to 158 ºF (-40 ºC to 70 ºC)
Humidity Indoor use, ≤ 95 %
Safety EN 6110-1:2010, Low Voltage Directive (LVD) 2014/35/EU
Electromagnetic Compatibility EN 61326-1:2013, EMC directive 2014/30/EU
Dimensions (W x H x D) 8.85” x 3.93” x 13.97” (225 mm x 100 mm x 355 mm)
Weight 5.51 lbs (2.5 kg)
Warranty 3 years
Standard Accessories Power cord, USB cable, test leads, spare fuses, test report and certificate of calibration
Optional Accessories
Rack mount kit (RK02), high performance bench DMM accessory kit (TL500B), general purpose DMM kit (TL130B),
Maxi-Pro DMM kit (TL50B), replacement probes (TL37)
Specifications
