4 Fluke Corporation 1587 FC/1577 Insulation Multimeters
1577 accuracy
Range Resolution 50 Hz to 60 Hz
± (% of Rdg + Counts)
600.0 mV 0.1 mV ± (2 % + 3)
6.000 V 0.001 V ± (2 % + 3)
60.00 V 0.01 V ± (2 % + 3)
600.0 V 0.1 V ± (2 % + 3)
1000 V 1 V ± (2 % + 3)
AC Conversion Inputs are ac coupled true-rms responding and specified from 5 % to 100 % of range. Input
signal crest factor can be up to 3 up to 500 V, decreasing linearly to a crest factor ≤1.5 at
1000 V. For non-sinusoidal waveforms add ± (2 % reading + 2 % FS) typical, for a crest factor
up to 3.
Input Impedance 10 MΩ (nominal), <100 pF, ac-coupled
Common mode
rejection ratio
(1 kΩ unbalanced)
>60 dB at dc, 50 or 60 Hz
DC voltage measurement
Range Resolution Accuracy 1587 FC
1
± (% of Rdg + Counts)
Accuracy 1577
1
± (% of Rdg + Counts)
6.000 V dc 0.001 V ± (0.09 % + 2) ± (0.2 % + 2)
60.00 V dc 0.01 V ± (0.09 % + 2) ± (0.2 % + 2)
600.0 V dc 0.1 V ± (0.09 % + 2) ± (0.2 % + 2)
1000 V dc 1 V ± (0.09 % + 2) ± (0.2 % + 2)
1
Accuracies apply to ± 100% of range.
Input Impedance: 10 MΩ (nominal), <100 pF
Normal mode rejection ratio: >60 dB @ 50 Hz or 60 Hz
Common mode rejection ratio: >120 dB @ dc, 50 Hz or 60 Hz (1 k unbalanced)
DC millivolts measurement
Range Resolution Accuracy 1587 FC
± (% of Rdg + Counts)
Accuracy 1577
± (% of Rdg + Counts)
600.0 mV dc 0.1 mV ± (0.1 % + 1) ± (0.2 % + 1)
DC and AC current measurement
Range Resolution Accuracy 1587 FC
± (% of Rdg+Counts)
Accuracy 1577
± (% of Rdg+Counts)
Burden voltage
(Typical)
AC
45Hz to
1000Hz
400 mA 0.1 mA ± (1.5 % + 2)
1
± (2 % + 2)
1
2 mV/mA
60 mA 0.01 mA ± (1.5 % + 2)
1
± (2 % + 2)
1
DC 400 mA 0.1 mA ± (0.2 % + 2) ± (1.0 % + 2) 2 mV/mA
60 mA 0.01 mA ± (0.2 % + 2) ± (1.0 % + 2)
1
1 kHz bandwidth
Overload: 600 mA for 2 minutes maximum
Fuse protection for mA Input: 0.44 mA, 1000 V, IR 10 kA
AC conversion: Inputs are ac coupled true-rms responding and specified from 5 % to 100 % of range. Input signal crest
factor can be up to 3 up to 300 mA, decreasing linearly to crest factor ≤1.5 at 600 mA. For non-sinusoidal waveforms
add +(2 % reading + 2 % FS) typical, for a crest factor up to 3.
