3 Fluke Corporation 1587 FC/1577 Insulation Multimeters
Electrical specifications
AC voltage measurement
Accuracy (1587 FC only)
Range Resolution 50 Hz to 60 Hz
± (% of Rdg +
counts)
60 Hz to 5000 Hz
± (% of Rdg + counts)
600.0 mV 0.1 mV ± (1 % + 3) ± (2 % + 3)
6.000 V 0.001 V ± (1 % + 3) ± (2 % + 3)
60.00 V 0.01 V ± (1 % + 3) ± (2 % + 3)
600.0 V 0.1 V ± (1 % + 3) ± (2 % + 3)
1
1000 V 1 V ± (2 % + 3) ± (2 % + 3)
1
1
1 kHz bandwidth
Low-Pass Filter Voltage (1587 FC only)
Range Resolution 50 Hz to 60 Hz
± (% of Rdg +
Counts)
60 Hz to 400 Hz
± (% of Rdg + Counts)
600.0 mV 0.1 mV ± (1 % + 3) + (2 % + 3) - (6 % - 3)
6.000 V 0.001 V ± (1 % + 3) + (2 % + 3) - (6 % - 3)
60.00 V 0.01 V ± (1 % + 3) + (2 % + 3) - (6 % - 3)
600.0 V 0.1 V ± (1 % + 3) + (2 % + 3) - (6 % - 3)
1000 V 1 V ± (2 % + 3) + (2 % + 3) - (6 % - 3)
General specifications cont.
Korea (KCC) Class A Equipment (Industrial Broadcasting & Communication Equipment)
Class A: Equipment meets requirements for industrial electromagnetic wave equipment
and the seller or user should take notice of it. This equipment is intended for use in busi-
ness environments and not to be used in homes.
USA (FCC) 47 CFR 15 subpart B. This product is considered an exempt device per clause 15.103.
Enclosure protection IEC 60529: IP40 (non-operating)
Safety IEC 61010-1 Pollution Degree 2
IEC 61010-2-033 CAT IV 600 V/CAT III 1000 V
Batteries Four AA batteries (NEDA 15A or IEC LR6)
Battery life Meter use 1000 hours; Insulation test use: Meter can perform at least 1000 insulation
tests with fresh alkaline batteries at room temperature. These are standard tests of
1000 V into 1 MΩ with a duty cycle of 5 seconds on and 25 seconds off.
Size 5.0 cm H x 10.0 cm W x 20.3 cm L (1.97 in H x 3.94 in W x 8.00 in L)
Weight 550 g (1.2 lb)
Altitude Operating 2000 m
Storage 12,000 m
Over-Range capability 110 % of range except for capacitance which is 100 %
Frequency overload protection <10
7
V-Hz
Fuse Protection for mA input 0.44A, 1000 V, IR 10 kA
