![Fluke FLK-1587MDTFC [6/8] Insulation specifications](/views2/1664834/page6/bg6.png)
6 Fluke Corporation 1587 FC/1577 Insulation Multimeters
Insulation specifications
Measurement range Model 1587 FC: 0.01 MΩ to 2 GΩ
Model 1577: 0.1 MΩ to 600 MΩ
Test voltages Model 1587 FC: 50, 100, 250, 500, 1000 V
Model 1577: 500, 1000 V
Test voltage accuracy +20 %, -0 %
Short-Circuit test current 1 mA nominal
Auto discharge Discharge time <0.5 second for C = 1 μF or less
Live circuit detection Inhibit test if terminal voltage > 30 V prior
to initialization of test
Maximum capacitive load Operable with up to 1 μF load
Model 1587 FC
Output voltage Display range Resolution Test current Resistance accuracy
± (% of Rdg + Counts)
50 V (0 % to +20 %)
0.01 to 6.00 MΩ 0.01 MΩ
1 mA @ 50 kΩ ± (3 % + 5 counts)
6.0 to 50.0 MΩ 0.1 MΩ
100 V (0 % to +20 %)
0.01 to 6.00 MΩ 0.01 MΩ
1 mA @ 100 kΩ ± (3 % + 5 counts)6.0 to 60.0 MΩ 0.1 MΩ
60 to 100 MΩ 1 MΩ
250 V (0 % to +20 %)
0.1 to 60.0 MΩ 0.1 MΩ
1 mA @ 250 kΩ ± (1.5 % + 5 counts)
60 to 250 MΩ 1 MΩ
500 V (0 % to +20 %)
0.1 to 60.0 MΩ 0.1 MΩ
1 mA @ 500 kΩ ± (1.5 % + 5 counts)
60 to 500 MΩ 1 MΩ
1000 V (0 % to +20 %)
0.1 to 60.0 MΩ 0.1 MΩ
1 mA @ 1 MΩ
± (1.5 % + 5 counts)
60 to 600 MΩ 1 MΩ
0.6 to 2.0 GΩ 100 MΩ ± (10 % + 3 counts)
Model 1577
500 V (0 % to +20 %)
0.1 to 60.0 MΩ 0.1 MΩ
1 mA @ 500 kΩ ± (2.0 % + 5 counts)
60 to 500 MΩ 1 MΩ
1000 V (0 % to +20 %)
0.1 to 60.0 MΩ 0.1 MΩ
1 mA @ 1 MΩ ± (2.0 % + 5 counts)
60 to 600 MΩ 1 MΩ
