Fluke FLK-179/MAG2 [2/4] Detailed specifications

Function Absolute Range or Description

AC Voltage, True-rms 0.1 mV to 1000V (1 kHz)

DC Voltage 0.1 mV to 1000V

Continuity Beeper guaranteed on < 25 Ω, guaranteed off > 250 Ω;

detects opens or shorts of 250 µs or longer.

Resistance 0.1Ω to 50.00 MΩ

Diode Test 2.400V

Capacitance 1 nF to 9999 uF

Nominal Specifications

Detailed Specifications

Accuracy ± ( [ % of Reading ] + [ Counts ] )

Function Range

1

Resolution Model 175 Model 177 Model 179

AC Volts

2

600.0 mV 0.1 mV 1.0 % + 3 1.0 % + 3 1.0 % + 3

6.000V 0.001V (45 Hz to 500 Hz) (45 Hz to 500 Hz) (45 Hz to 500 Hz)

60.00V 0.01V

600.0V 0.1V

1000V 1V 0.15 % + 2 0.1 % + 2 0.1 % + 2

Continuity 600Ω 1Ω Meter beeps at < 25 Ω, beeper turns off at > 250 Ω;

detects opens or shorts of 250 ms or longer.

Ohms 600.0Ω 0.1Ω 0.9 % + 2 0.9 % + 2 0.9 % + 2

6.000 kΩ 0.001 kΩ 0.9 % + 1 0.9 % + 1 0.9 % + 1

60.00 kΩ 0.01 kΩ 0.9 % + 1 0.9 % + 1 0.9 % + 1

600.0 kΩ 0.1 kΩ 0.9 % + 1 0.9 % + 1 0.9 % + 1

6.000 MΩ 0.001 MΩ 0.9 % + 1 0.9 % + 1 0.9 % + 1

50.00 MΩ 0.01 MΩ 1.5 % + 3 1.5 % + 3 1.5 % + 3

Diode test 2.400V 0.001V 1 % + 2

(True-rms) 400.0 mA 0.1 mA

(600 mA for 18 hrs) 0.001A

6.000A

(45 Hz to 1 kHz) 10.00A 0.01A

(20A for 30s)

DC Amps 60.00 mA 0.01 mA 1.0 % + 3 1.0 % + 3 1.0 % + 3

400.0 mA 0.1 mA

(600 mA for 18 hrs)

6.000A 0.001A

10.00A 0.01A

Temperature -40 °C to +400 °C 0.1 °C NA NA 1 % + 1.0 °C

-40 °F to +752 °F 0.1 °F 1 % + 1.8 °F

MIN MAX AVG For DC functions, accuracy is the specified of the measurement function ± 12 counts for changes

longer than 275 ms in duration.

For AC functions, accuracy is the specified of the measurement function ± 40 counts for changes

longer than 1.2 s in duration.

1. All AC voltage and AC current ranges are specified from 5 % of range to 100 % of range.

2. Crest factor of ≤ 3 at full scale up to 500 V, decreasing linearly to crest factor ≤ 1.5 at 1000 V.

3. In the 9999 µF range for measurements to 1000 µF, the measurement accuracy is 1.2 % for all models.

4. In mA and A ranges, frequency measurement is specified to 30 kHz.
