Fluke FLK-179/MAG2 [3/4] General speciﬁcations

Function Overload Protection

Input Impedance Common Mode Rejection Ratio Normal Mode Rejection

(Nominal) (1 kΩ Unbalanced)

Volts AC 1000 V RMS or DC > 10 MΩ < 100 pF > 60 dB @ DC, 50 or 60 Hz

Volts DC 1000 V RMS or DC > 10 MΩ <100 pF >120 dB @ DC, 50 or 60 Hz > 60 dB @ 50 Hz or 60 Hz

Open Circuit Test Full Scale Voltage To: Short Circuit Current

Voltage 6.0 MΩ 50 MΩ

Ohms 1000V RMS or DC < 1.5 V DC < 600 mV DC < 1.5 V DC < 500 µA

Diode test 1000V RMS or DC 2.4 to 3.0 V DC 2.4 V DC < 1.2 mA typical

1. 10

V-Hz maximum.

General Speciﬁcations

Maximum voltage between any 1000V DC or AC RMS

terminal and earth ground

Surge Protection 8 kV peak per IEC 61010

Fuse for mA inputs 440 mA, 1000 V FAST Fuse

Fuse for A input 11A, 1000V FAST Fuse

Display Digital: 6,000 counts, updates 4/sec

Bar Graph: 33 segments, updates 40/sec

Frequency: 9,999 counts

Capacitance: 9,999 counts

Altitude Operating: 2000 m; Storage: 12000 m

Temperature Operating: -10 °C to +50 °C

Storage: -30 °C to +60 °C

Temperature coefﬁcient 0.1 X (speciﬁed accuracy / °C)

(< 18 °C or > 28 °C)

Electromagnetic Compatibility In an RF ﬁeld of 3 V/M, accuracy = speciﬁed accuracy except in

(EN 61326-1:1997) temperature: speciﬁed accuracy ± 5 °C, ± 9 °F

Relative Humidity 0 % to 90 % @ 0 °C to 35 °C;

0 % to 70 % @ 36 °C to 50 °C

Relative Humidity in 0 % to 80 % @ 0°C to 35°C;

50 MΩ Range 0 % to 70 % @ 36 °C to 50 °C

Battery Life Alkaline: ~200 hrs typical

Size, with Holster (H x W x L) 4.3 cm x 9 cm x 18.5 cm

Weight 420g

Safety Compliances ANSI/ISA S82.02.01, CSA C22.2-1010.1, IEC 61010 to 1000 V Overvoltage

Category III, 600 V Overvoltage Category IV

Certiﬁcations CSA, TÜV (EN61010),

Australian (N10140)
