FEATURES ACD-10 TRMS-PLUS ACD-10 PLUS

TRMS Measurement

Yes N/A

AC Voltage

4.000, 40.00, 400.0, 600V

DC Voltage

400.0m, 4.000, 40.00, 400.0, 600V

AC Current

40.00, 400.0, 600A

Resistance with

Continuity Buzzer

0-400.0 Ω, 4.000 kΩ, 40.00 kΩ, 400.0 kΩ,

4.000 MΩ, 40.00 MΩ

Capacitance

500.0nF, 5.000µF, 50.00µF, 500.0µF, 3000µF

Frequency

(Using Jaw or Test Leads)

40-400Hz with Jaw,

10Hz to 100kHz with test leads

FEATURES ACD-14 FX ACD-14 TRMS-FX ACDC-400

TRMS Measurement

N/A Yes N/A

AC Voltage

4.000, 40.00, 400.0, 600 V

400.0 m, 4.000, 40.00, 400.0,

600 V

DC Voltage

4.000, 40.00, 400.0, 600 V

400.0 m, 4.000, 40.00, 400.0,

600 V

AC Current

40.00 / 400.0 A 40.00 / 400.0 A

DC Current

N/A 40.00 / 400.0 A

AC/DC Micro Amps (Using

Test Leads)

400µA, 2000 µA N/A

Resistance with

Continuity Buzzer

0-400.0 Ω, 4.000 kΩ, 40.00 kΩ, 400.0 kΩ,

4.000MΩ, 40.00 MΩ

Capacitance

500.0nF, 5.000µF, 50.00µF, 500.0µF, 3000µF N/A

Frequency (Using Jaw or

Test Leads)

10Hz to 100kHz N/A

Temperature

-20°C to 300°C N/A

600A Clamp Multimeters

B TRMS Measurement (ACD-10 TRMS PLUS only)

B AC and DC Voltage to 600V

B AC Current to 600A

B Resistance to 40 MΩ with

Continuity Buzzer

B Capacitance to 3000 µF

B Frequency measurement

B Hold & Maximum reading functions

B Auto ranging

B Thinner jaws (approx 6.35mm thinner)

B In Rush Current

B Jaw opening 25 mm

B Safety acc. EN 61010, CAT III/600 V

ACD-10 PLUS, ACD-10 TRMS-PLUS

Clamp Multimeters with Unique Thin Jaws

400A Clamp Multimeters

ACD-14 PLUS, ACD-14 TRMS-PLUS

Digital Clamp Multimeters

The ACD-14 Plus is the professionals’ choice for both HVAC & Electrical applications due to

its complete set of measuring features. Its dual displays allows viewing amperage and voltage

measurements simultaneously.

B TRMS Measurement (ACD-14 TRMS-PLUS only)

B Dual Displays - Permits simultaneous reading

of Amperage & Voltage

B Micro Amps measurement for testing “Flame

Sensors”

B Capacitance to 3000 µF

B Temperature w/Type-K Thermocouple

B AC and DC Voltage to 600V

B AC current to 400A

B Resistance to 40MΩ

B Continuity Buzzer

B Frequency Measurement

B Auto Power Off

B Auto Ranging

B Hold & Maximum Readings

B In Rush Current

B Jaw opening 26 mm

B Safety acc. EN 61010, CAT III/600 V

400 A AC range

B 600 V AC and range AC40B)

B 4000-count display with bargraph

B 10mA resolution in lowest range

Data Hold

B Auto power-off

B Jaw opening 25 mm

B Safety EN 61010, CAT III/600 V

Amprobe’s ACD-10 PLUS meters offer thinner jaws over standard clamp meters. Allowing access

to tight measurement areas and still accomodating conductors up to 25 mm (1 in). Both meters

also measure Capacitance and Frequency. Frequency is measured by either jaws or test leads.

Very versatile clamp multimeters.

CLAMP METERS

ACDC-400 Digital AC/DC Clamp Multimeter

This versatile clamp multimeter offers numerous measurement features in a

professional sized package.Versatile and rugged for facility maintenance to field service.

B AC/DC Current up to 400A

B AC/DC Voltage up to 600V

B Resistance measurement

B Continuity test

B Data Hold

B MAX/MIN recording

B Relative measurement

B Backlight

B Analog bargraph

B Auto or Manual range selection

B “Third hand” - test probe holder

B Jaw opening 30 mm

B Safety acc. EN 61010, CAT III/600 V

For detailed specifications go to www.Amprobe.eu
