Industrial Scanner

HST-Lite

The new HST-Lite scanner is the perfect choice for cost-

effective, one-channel TOFD inspections when signal quality is

important. The combination of magnetic wheels and spring-

loaded probe holders offer the stability required to perform

high quality, one-line inspections. The scanner can be oper-

ated using only one hand, and will attach to ferromagnetic

surfaces even when in an upside-down position.

The scanner’s position can be encoded around the cir-

cumference of pipes as small as 4.5 in. (114.3 mm) OD, as

well as on ﬂat surfaces. Adjustment of the different scanner

components can be performed without tools.

Features

• Circumferential scans performed with two TOFD probes on

pipes 4.5 in. (114.3 mm) OD, or greater.

• Four magnetic wheels ﬁrmly attach the unit to ferromagnetic

inspection surfaces.

• Light aluminum frame.

• Independently positioned and spring-loaded probe holders.

• Waterproof, spring-loaded encoder with 9 step/mm resolution.

• Removable handle for lower proﬁle.

• Attachment devices for umbilical cables.

• The frame design enables probes to be positioned outside the

wheels (2 additional magnetic wheels are required).

• Engraved references on the scanner and pointer on the probe

holders ensure easy probe separation measurement.

TOFD Weld Inspection

Manual One-Axis Scanner
