Olympus HSMT-Flex [3/3] Tofd probes and wedges ordering information

www.olympusNDT.com

info@olympusNDT.com

All brands are trademarks or registered trademarks of their respective owners.

Olympus NDT

48 Woerd Avenue • Waltham, MA 02453 • USA

Tel.: (1) 781-419-3900 • Fax: (1) 781-419-3980

12569 Gulf Freeway • Houston, TX 77034 • USA

Tel.: (1) 281-922-9300 • Fax: (1) 952-487-8877

Olympus NDT u.K. lTD.

12 Nightingale Close • Rotherham, South Yorkshire S60 2AB • UK

Olympus siNgapOre pTe. lTD.

491B River Valley Road 12-01/04, Valley Point Ofce Tower, 248373 • Singapore

Olympus ausTralia pTy. lTD.

PO Box 985 • Mount Waverley, VIC 3149 • Australia

TOFD Probes and Wedges Ordering Information

High-sensitivity composite probes to fit ST1 wedge type

Part number Frequency (MHz) Element diameter (mm) Connector type

C542-SM 2.25 6.0 Microdot

C543-SM 5.0 6.0 Microdot

C544-SM 10.0 6.0 Microdot

C563-SM 10.0 3.0 Microdot

High-sensitivity composite probes to fit ST2 wedge type

C540-SM 2.25 12.5 Microdot

C541-SM 5.0 12.5 Microdot

ST1 TOFD wedges to fit TOFD/PE yoke

Part number Refracted angle (º) Wedge option group

ST1-45L 45 Plain

ST1-45L-IHC 45 IHC

ST1-60L 60 Plain

ST1-60L-IHC 60 IHC

ST1-70L 70 Plain

ST1-70L-IHC 70 IHC

ST2 TOFD wedges to fit TOFD/PE yoke

Part number Refracted angle (º) Wedge option group

ST2-45L 45 Plain

ST2-45L-IHC 45 IHC

ST2-60L 60 Plain

ST2-60L-IHC 60 IHC

ST2-70L 70 Plain

ST2-70L-IHC 70 IHC

UT Probes and Wedges Ordering Information

High-sensitivity composite probes for pulse-echo to fit SPE2 wedges

Part number Frequency (MHz) Element diameter (mm) Connector type

C549-SM 2.25 9.5 Microdot

C550-SM 3.5 9.5 Microdot

C551-SM 5.0 9.5 Microdot

SPE2 wedges to fit TOFD/PE yoke

Part number Refracted angle (º) Wave type Wedge option group

SPE2-45S-IHC 45 Shear IHC

SPE2-60S-IHC 60 Shear IHC

SPE2-70S-IHC 70 Shear IHC

IHC: irrigation holes and carbide wear pins
