906211594 - Ed. 1 - VS - 11/2019 - Non-contractual document. Specifications subject to modifications linked to technological developments.
PAC 15 PAC 16 PAC 17 PAC 25 PAC 26 PAC 27
For multimeters, loggers, etc. For oscilloscopes For multimeters, loggers, etc. For oscilloscopes
Measurement range(s)
0.5 .. 400 A AC RMS
0.5 .. 600 A DC
0.5 .. 40 A AC RMS
0.5 .. 60 A DC
0.5 .. 400 A AC RMS
0.5 .. 600 A DC
0.5 .. 40 A AC RMS
0.5 .. 60 A DC or peak
0.5 .. 400 A AC RMS
0.5 .. 600 A DC or peak
0.5 .. 1000 A AC RMS
0.5 .. 1400 A DC
0.5 .. 100 A AC RMS
0.5 .. 150 A DC
0.5 .. 1000 A AC RMS
0.5 .. 1400 A DC
0.5 .. 100 A AC RMS
0.5 .. 150 A DC or peak
0.5 .. 1000 A AC RMS
0.5 .. 1400 A DC or peak
Bandwidth
(1)
DC .. 30 kHz (-3 dB) DC .. 30 kHz (-3 dB)
Sensitivity 1 mV/A
10 mV/A
1 mV/A
1 mV/A
10 mV/A
1 mV/A
Best accuracy
(2)
1.5 % + 1 mV 1.5 % 1.5 % + 1 mV 1.5 %
Output connector Ø 4mm isolated elbowed male safety plugs Isolated male BNC Ø 4mm isolated elbowed male safety plugs Isolated male BNC
Length of built-in cable 1.5 m 2 m 1.5 m 2 m
Admissible load of measuring
instrument
≥ 1 MΩ / ≤ 100 pF ≥ 1 MΩ / ≤ 100 pF
Power supply 9 V battery / 5 V DC µUSB type B 9 V battery / 5 V DC µUSB type B
Battery life
(3)
50 hours typical 50 hours typical
Specific functions
Standby function automatic deactivatable automatic deactivatable
DC Zero Automatic Automatic
LED indications
External power supply / Battery status
Standby status
Measurement capacity overrun
DC Zero acknowledgement
External power supply / Battery status
Standby status
Measurement capacity overrun
DC Zero acknowledgement
Maximum conductor diameter Cables: Ø 30 mm / Busbars: 50 x 10 mm Cables: Ø 39 mm / Busbars: 50 x 12.5 mm
Dimensions 224 x 97 x 44 mm 236 x 97 x 44 mm
Weight 440 g with battery 520 g with battery
Climatic conditions
Operation -10 °C to +55 °C / < 85 % RH -10 °C to +55 °C / < 85 % RH
Storage -40 °C to +80 °C / < 85 % RH -40 °C to +80 °C / < 85 % RH
Compliance with standards
Electrical safety IEC 61010-1 & IEC 61010-2-032 600 V CAT III / 300 V CAT IV IEC 61010-1 & IEC 61010-2-032 600 V CAT III / 300 V CAT IV
Electromagnetic compatibility IEC 61326-1 IEC 61326-1
Self-extinguishing capability Jaws and casing: UL94 V1 Jaws and casing: UL94 V1
PAC Series - AC/DC Hall-eect current clamps
() depending on current value - () Best uncertainty in % of output signal - () on battery
Technical specifications
State at delivery
Delivered in a cardboard box containing:
PAC clamp,   V battery,  user's manual in
languages (F, GB, D, I, E),  safety datasheet
(languages),  verification certificate.
To order
PAC 15 clamp
P01120115
PAC 16 clamp
P01120116
PAC 17 oscillo clamp
P01120117
PAC 25 clamp
P01120125
PAC 26 clamp
P01120126
PAC 27 oscillo clamp
P01120127
110/230 V 50/60 Hz adapter
USB 5 Vdc and USB/µUSB cable
P01651023
9 V alkaline battery P01100620
MF bag 120 X 245 X 60 CA P01298075
Accessories / Replacement parts
