15) BAT (Battery)

 Thebatteryprovidespowertokeepthevalues(suchasBIOScongurations,date,andtimeinformation)

in the CMOS when the computer is turned off. Replace the battery when the battery voltage drops to a low

level, or the CMOS values may not be accurate or may be lost.

You may clear the CMOS values by removing the battery:

1. Turn off your computer and unplug the power cord.

2. Gently remove the battery from the battery holder and wait for one minute. (Or use a

metal object like a screwdriver to touch the positive and negative terminals of the battery

holder, making them short for 5 seconds.)

3. Replace the battery.

4. Plug in the power cord and restart your computer.

• Always turn off your computer and unplug the power cord before replacing the battery.

• Replacethebatterywithanequivalentone.Damagetoyourdevicesmayoccurifthebatteryis

replaced with an incorrect model.

• Contact the place of purchase or local dealer if you are not able to replace the battery by yourself

or uncertain about the battery model.

• Wheninstallingthebattery,notetheorientationofthepositiveside(+)andthenegativeside(-)

of the battery (the positive side should face up).

• Used batteries must be handled in accordance with local environmental regulations.

16) CLR_CMOS (Clear CMOS Jumper)

 UsethisjumpertocleartheBIOScongurationandresettheCMOSvaluestofactorydefaults.Toclear

the CMOS values, use a metal object like a screwdriver to touch the two pins for a few seconds.

• Always turn off your computer and unplug the power cord from the power outlet before clearing

the CMOS values.

• Aftersystemrestart,gotoBIOSSetuptoloadfactorydefaults(selectLoadOptimizedDefaults)or

manuallyconguretheBIOSsettings(refertoChapter2,"BIOSSetup,"forBIOScongurations).

Open: Normal

Short: Clear CMOS Values

Pin No. Denition Pin No. Denition

1 VBUS 11 D2+

2 SSRX1- 12 D2-

3 SSRX1+ 13 GND

4 GND 14 SSTX2+

5 SSTX1- 15 SSTX2-

6 SSTX1+ 16 GND

7 GND 17 SSRX2+

8 D1- 18 SSRX2-

9 D1+ 19 VBUS

10 NC 20 No Pin

17) F_USB30 (USB 3.1 Gen 1 Header)

 TheheaderconformstoUSB3.1Gen1andUSB2.0specicationandcanprovidetwoUSBports.For

purchasing the optional 3.5" front panel that provides two USB 3.1 Gen 1 ports, please contact the local

dealer.

F_USB30

F_U

B_ 

F_  F_ 



_

B

BS_

B

SB_

B

_S



S_

_

B

_U

_

B





 

S  

 

123

 

123

 

123

 

123

BSS

S

_S 

SSU

 

1 2 3 4 5

 S3

BSSS



U

 __ 3

F_USB3F

S  _

SF





B_

F

_0

S

S

_0F

_F

_

_

__B





U

S  _S

_

SF_

USB0_B

B_

F_USB3



F_USB303



_



_3U

- 19 -
