Gigabyte B550 AORUS PRO AX [13/48] Audio jack configurations
![Gigabyte B550 AORUS PRO AX [13/48] Audio jack configurations](/views2/1666225/page13/bgd.png)
Please visit GIGABYTE's website for details on conguring the audio software.
If you want to install a Side Speaker, you need to retask either the Line in or Mic in jack to be
Side Speaker out through the audio driver.
Audio Jack Congurations:
Jack
Headphone/
2-channel
4-channel 5.1-channel 7.1-channel
Center/Subwoofer Speaker
Out
a a
Rear Speaker Out
a a a
Line In/Side Speaker Out
a
Line Out/Front Speaker Out
a a a a
Mic In/Side Speaker Out
a
- 13 -
