9
Model UT233: OPERATING MANUAL
Functional Buttons
Below table indicated for information about the functional
button operations.
Button
POWER
HOLD
LIGHT
MENU
Button
MENU
Operation Performed
Press MENU to display the following
functions in sequence:
Operation Performed
Press and hold POWER for 1 second
to turn the Meter on.
Press POWER again to turn the
Meter off.
Press HOLD to enter the Hold mode in
any mode,
appears and
the Meter
beeps.
Press HOLD again to exit the Hold mode
to return to measurement mode, the
Meter beeps and
disappears.
H
H
Press LIGHT to turn the display backlight
on.
The display backlight will be off
automatically after 30 seconds.
Button
POWER
HOLD
LIGHT
MENU
Active power (main display) + AC
Voltage (left secondary display) + AC
Current (right secondary display)
Apparent Power (main display) + AC
Voltage (left secondary display) + AC
Current (right secondary display)
Reactive Power (main display) + AC
Voltage (left secondary display) + AC
Current (right secondary display)
Power Factor (main display) + AC
Voltage (left secondary display) + AC
Current (right secondary display)
Phase Angle (main display) + AC
Voltage (left secondary display) + AC
Current (right secondary display)
Frequency (main display) + AC Voltage
(left secondary display) + AC Current
(right secondary display)
Active Energy (main display) + Active
Power (left secondary display) + Time
(right secondary display)
