Uni-T UT233 [39/50] Specifications

Specifications

A. General Specifications

Model UT233: OPERATING MANUAL

Maximum Voltage between any Terminals and

grounding: Refer to different range input protection

voltage.

Display: Multi LCD displays, Maximum display 9999.

Ranges: Auto

Overloading: Display OL.

Battery Deficiency: Display ..

Data Holding: Display

Data Logging: Maximum 99, Single or Continuous

record and recall data

Maximum and Minimum value display: Voltage,

Current, Active Power, Apparent Power and Reactive

Power ranges

Display Backlight

Computer connection: USB

Sleep Mode: To preserve battery life, the Meter

automatically turns off if you do not turn press any

button for around 15 minutes., except at active

energy range.

Analogue Bar Graph

Sampling: High speed: 2 times per second, Low

speed: 1 time per 3 seconds, Mid speed: 1 time per

2 seconds.

Max. Jaw Size: 55mm diameter.

Power: 4 x 1.5V Alkaline battery (LR6 AA)

Dimensions: 303mm x 112mm x 39mm

Weight: Approximate 601g
