BEHA-AMPROBE BM035 [2/4] Bm037 bm035 bm033

FUNCTIONS & FEATURES

600A AC Extra-slim Jaws, Max 26mm conductor size

Line-level ACV Frequency (LPF Added) 5.00Hz up to 999.9Hz

DCμA ranges 200.0μA to 2000μA (via probes) for HVAC flame sensors

Cx ranges 200.0μF to 2500μF for start & run motor capacitors

Type-K temperature -40.0ºC to 400ºC or -40.0ºF to 752ºF selectable

Regular DCA 600.0A range + AmpTip

DCA 60.00A range

Ohm ranges 600.0Ω, 6.000kΩ, 60.00kΩ, 600.0kΩ, ~6000kΩ

037 035

033 031

~6kΩ ~6kΩ

600A DC/AC Hall-effect Jaws, Max 26mm conductor size

EMC EN61326-1

LVD EN61010-1/61010-2-032/61010-2-033 to CAT-III 600V & CAT-IV 300V

Transient protection 6kV 1.2/50μs lightning surge

Rugged fire retarded housing

Soft carrying pouch

Regular ACA 600.0A range + AmpTip

ACA 60.00A range

BeepLit

Diode. Features 0.85V Beep-Alert, and <0.1V BeepLitTM effects

BeepLit

Continuity. Features Audible Beep & Visible Backlight effects

ACV (LPF Added) range 600.0V; DCV range 600.0V

Probe-Contact EF-Detection for more precise indication of live

Non-Contact EF-Detection (NCV) with Hi/Lo Selectable Sensitivities

Relative mode (Auto-ranging) with DC-Zero mode on DCA ranges

5ms CREST MAX/MIN mode to capture instantaneous +Peak & -Peak

RECORD MAX/MIN mode (Auto-ranging)

Intelligent Auto Power Off

Back-lighted easy-to-read LCD Display

LPF Added On ACV For Fundamentals Of VFDs And Noisy Signals

True RMS AC Voltage and Current functions

600V AC/DC input protection on General functions

AmpTip

Low-current-range calibrated at Jaw-tip for thin-conductors

6,000 counts 3-5/6 digits LCD display; Updates 5/sec

Data HOLD

BM030 Series │ Patented AmpTip

Jaws Clamp-on DMM │ www.brymen.com BRYMEN

BM037

BM035

BM033 BM031
