BEHA-AMPROBE BM035 [4/4] General specifications electrical specifications

GENERAL SPECIFICATIONS ELECTRICAL SPECIFICATIONS

Accuracy is ±(% reading digits + number of digits) or

otherwise specified, at 23°C ± 5°C.

Maximum Crest Factor < 2 : 1 at full scale & < 4 : 1 at

half scale or otherwise specified, and with frequency

spectrum not exceeding the specified frequency

bandwidth for non-sinusoidal waveforms.

BRYMEN TECHNOLOGY CORPORATION

RANGE

200.0μA, 2000μA 1.0% + 5d 3.5mV/μA

Accuracy Burden Voltage

DCμA (BM037 & BM033 only)

EF-L

(Lo Sensitivity)

Typical Voltage (Tolerance)

10V (2V ~ 20V) 40V (10V ~ 70V)

20V (4V ~ 40V) 80V (20V ~ 140V)

40V (8V ~ 70V) 160V (40V ~ 280V)

80V (16V ~ 140V) 320V (80V ~ 560V)

160V (>40V) 500V (>160V)

Non-Contact EF-Detection

EF-H

(Hi Sensitivity)

Bar-Graph

Indication

- -

- - -

- - - -

- - - - -

Indication: Bar-graph segments & audible beep

tones proportional to the field strength

Detection Frequency: 50/60Hz

Detection Antenna: Inside the top side of the

stationary jaw

Probe-Contact EF-Detection: For more precise

indication of live wires, such as distinguishing

between live and ground connections, use one

single probe to test via terminal COM for direct

metal Probe-Contact EF-Detection to achieve

the most distinctive indication.

Display: 3-5/6 digits 6000 counts

Polarity: Automatic

Update Rate: 5 per second nominal

Operating Temperature: 0°C to 40°C

Relative Humidity: Maximum relative humidity 80%

for temperature up to 31°C decreasing linearly to

50% relative humidity at 40°C

Pollution degree: 2

Storage Temperature: -20°C to 60°C, < 80% R.H.

(with battery removed)

Altitude: Operating below 2000m

Temperature Coefficient: nominal 0.1 x (specified

accuracy)/ °C @(0°C -- 18°C or 28°C -- 40°C), or

otherwise specified

Sensing: True RMS

Safety: Certified per IEC/UL/CSA_C22.2_#/EN

standards:

61010-1 Ed. 3.0, 61010-2-032 Ed. 3.0, 61010-2-

033 Ed. 1.0 & 61010-031 Ed. 2.0 to

Measurement Categories CAT III 600V and CAT IV

300V ac & dc

Transient Protection: 6.0kV (1.2/50µs surge)

Overload Protections:

Current via jaws: 600Adc/Aac rms at <400Hz

Voltage via terminals: 660Vdc / 920Vac rms

Other functions via terminals: 600Vdc/Vac rms

E.M.C.: Meets EN61326-1

DCA and ACA Functions, in an RF field of 1V/m:

Total Accuracy = Specified Accuracy + 40

digits at around 87MHz

DCµA and Ohm Functions, in an RF field of 1V/m:

Total Accuracy = Specified Accuracy + 25 digits

Other Functions, in an RF field of 3V/m:

Total Accuracy = Specified Accuracy + 20 digits

Power Supply: 1.5V AAA Size battery X 2

Power Consumption: Typical 14mA for Current

functions of BM037 & BM035; 4mA for others

Low Battery Indication:

Below approx. 2.85V for Capacitance & Hz

Below approx. 2.5V for other functions

APO Timing: Idle for 32 minutes

APO Consumption: 5µA typical

Dimension (LxWxH): 188 x 66 x 32mm

Weight: 202g for BM037 & BM035; 158g for

BM033 & BM031

Jaw opening & Conductor diameter : 26mm max

Accessories: Test lead set, User's manual, Soft

carrying pouch, Bkp60 banana plug type-K

thermocouple (BM037 & BM033 only),

Optional purchase accessories: BKB32 banana

plug to type-K socket plug adaptor (BM037 &

BM033 only)

Special Features: AmpTip

low-current range;

MAX/MIN Recording mode; MAX/MIN Crest (Peak-

Hold) mode; Relative-Zero mode; Display Hold; EF-

Detection (NCV); BeepLit

Feature

RANGE

600.0V 1.0% + 5d

Accuracy

DC Voltage

Input Impedance: 10M

Ω

, 100 pF nominal

RANGE

600.0V

50Hz ~ 60Hz

1.5% + 5d

Accuracy

AC Voltage (with Low-Pass Filter)

Input Impedance: 10M

Ω

, 100 pF nominal

RANGE

600.0

Ω

, 6.000K

Ω

(All models)

Ohm

Accuracy

1.0% + 5d

600.0

Ω, 60.00kΩ, 600.0kΩ,

6000k

Ω

(BM037 & BM033 only)

Open Circuit Voltage: 1.0VDC typical

RANGE

200.0μF, 2500μF 2.0% + 4d

Accuracy

Capacitance (BM037 & BM033 only)

Accuracies with film capacitor or better

RANGE

3.000V 1.5% + 5d

Accuracy

BeepLit™ Diode Tester

Test Current: 0.3mA typically

Open Circuit Voltage: < 3.5VDC typically

Short Beep Alert Threshold: Drop across 0.850V

BeepLit™ ON Threshold: < 0.100V

Audible Indication: Beep sound

Visible Indication: LCD Backlight

RANGE

-40.0 °C ~ 99.9 °C

1.0% + 1.0°C

1.0% + 1°C

1.0% + 2.0°F

1.0% + 2°F

100 °C ~ 400 °C

-40.0 °F ~ 211.8 °F

212 °F ~752 °F

Temperature (BM037 & BM033 only)

Accuracy

1) 2)

Accuracies assume meter interior has the same

temperature of the ambient (isothermal stage) for

a correct junction voltage compensation. Allow the

meter and the type-K probe set to reach isothermal

stage for a significant change of ambient

temperature. It can take up to an hour for changes

> 5°C.

Type-K thermocouple range & accuracy not

included

RANGE

60.00A

50Hz ~ 60Hz

1.0% + 5d

Accuracy

Clamp-on AmpTip

ACA

Induced error from adjacent current-carrying

conductor:

<0.01A/A for BM037 & BM035

<0.06A/A for BM033 & BM031

RANGE

60.00A 1.0% + 5d

Accuracy

1) 2) 3)

Clamp-on AmpTip

DCA (BM037 & BM035 only)

Induced error from adjacent current-carrying

conductor: <0.01A/A

Specified with DC-Zero mode applied to offset the

non-zero residual readings, if any

Add 5d to the specified accuracy @ < 4A

RANGE

50Hz ~ 100Hz

1.5% + 5d

2.0% + 5d

600.0A

100Hz ~ 400Hz

600.0A

Clamp-on Regular ACA

Accuracy

1) 2)

Induced error from adjacent current-carrying

conductor:

<0.1A/A for BM037 & BM035

<0.6A/A for BM033 & BM031

For BM033 & BM031, specified accuracy is for

measurements made at the jaw center. When the

conductor is not positioned at the jaw center, add

2% to specified accuracy for position errors

RANGE

600.0A 2.0% + 5d

Accuracy

1) 2)

Clamp-on Regular DCA (BM037 & BM035 only)

Induced error from adjacent current-carrying

conductor: <0.1A/A

Specified with DC-Zero mode applied to offset

the non-zero residual readings, if any

Function Range

Hz Line Level Frequency (BM037 & BM033 only)

Sensitivity

(Sine RMS)

600V 5.00Hz ~ 999.9Hz50V

Accuracy: 1%+5d

DC-bias, if any, not more than 50% of Sine RMS

BeepLit™ Continuity Tester:

Continuity Threshold: Between 30Ω and 480Ω

Continuity ON Response Time: 15ms approx.

Audible Indication: Beep sound

Visible Indication: LCD Backlight

CREST (Peak-Hold):

Applicability: Voltage and Non-invasion Current

functions

Accuracy: Add +/- 250 digits to specified

accuracy for changes > 5ms in duration

www.brymen.eu
