380926 -EN-V7.1-3/12

Conductor Size 2.0”(50mm) maximum

Measurement parameters ACA, DCA, ACV, DCV, Resistance, Diode, Frequency,

Capacitance, Duty Cycle, Continuity

Current Sensor Hall Effect

Zero adjust Automatic except for DCA (Push-button)

Diode Test Test current of 0.6mA typical;

Open circuit voltage <1.6V DC typical.

Battery type 9V NEDA 1604

Range Selection Auto or manual

Display 0.6” (15mm) 5000 Count Backlit LCD

Overload Indication "OL"

Power Consumption 5mA approx.

Low Battery Indication Battery icon appears on LCD

Sampling rate 1 reading every 0.35 seconds approx.

Standards CE, IEC 1010-1 CAT III 1000V and CAT IV 600V

Operating Temperature/Humidity 32 to 122

F (0

C to 50

C) / <80%

Dimensions 10 x 2.9 x 1.5” (255 x 73 x 38mm)

Weight 0.85 lbs. (380g)

Maximum Rated Input Limits

Function Maximum Rated Input Limits

AC/DC Current 500mA AC/DC (fused)

AC Voltage 1000 VAC/DC

DC Voltage 1000 VAC/DC

Resistance 400 VAC/DC

Frequency 1000 VAC/DC

Capacitance 400 VAC/DC

Duty Cycle 1000 VAC/DC

Diode Test 400 VAC/DC
