380926 -EN-V7.1-3/12
8
SPECIFICATIONS
Function Range Resolution Accuracy Remarks
400.0A 0.1A ±(2.0% + 5d) AC/DC Current
(Clamp on)
2000A 1A ±(2.0% + 8d)
45Hz to 1KHz
4.000V 1mV
40.00V 10mV
400.0V 0.1V
AC Voltage
True RMS
1000V 1V
±(1.2% + 5d) 45Hz to 1KHz
Input Impedance:
10Mohms
400.0mV 0.1mV ±(0.5% + 2d)
4.000V 1mV
40.00V 10mV
400.0V 0.1V
DC Voltage
1000V 1V
±(1.0% + 2d)
Input Impedance:
10Mohms
400.0 Ω 0.1Ω
4.000 kΩ 1Ω
40.00 kΩ 10Ω
400.0 kΩ 100Ω
±(1.0% + 5d)
4.000 MΩ 1kΩ
±(2.0% + 2d)
Resistance
40.00 MΩ 10kΩ
±(3.5% + 5d)
400.0µA 0.1µA
4000µA 1µA
40.00mA 0.01mA
AC/DC Current
(Direct Input)
400.0mA 0.1mA
±(1.2% + 5d) 45Hz to 1KHz
5Hz 0.001Hz
50Hz 0.01Hz
500Hz 0.1Hz
5kHz 1Hz
50kHz 10Hz
Frequency
100kHz 100Hz
±(1% + 5d)
50nF 10pF
500nF 100pF
5µF 0.001µF
Capacitance
50µF 0.01µF
±(3% + 5d) Accuracy stated
after a relative "REL"
zero performed
Duty Cycle 1 to 99% 0.1% ±(1% + 5d)
Continuity Audible tone; <10 ohms approximately
Open circuit voltage; 0.5V approximately
