Ordering Information:

EX622..........True RMS 400A AC Clamp Meter + IR Thermometer

EX623..........True RMS 400A AC/DC Clamp Meter + IR Thermometer

Specifications subject to change without notice.

www.extech.com

Built-in IR Thermometer with laser

pointer is an excellent troubleshooter

for locating hot spots and overheating

motors.

09/05/07 - R1

Features:

• Non-contact InfraRed Temperature measurements

with laser pointer; 6:1 Distance to Target ratio

• Dual Differential Type K Thermocouple Temperature function

(T1, T2, and T1-T2)

• DC µA current measurement

• MultiMeter functions include AC/DC Voltage, Resistance,

Capacitance, Frequency, Diode, and Continuity

• 1.2" (30mm) jaw opening for conductors up to 500MCM

• 4000 count backlit dual display

• Features include Data Hold and Max Hold

• Autoranging with manual range button

• Auto Power off with Auto Power off disable

• Complete with test leads, 9V battery, two Type K bead wire

probes (-4 to 482°F/-20 to 250°C), and case

Clamp meters with built-in IR Thermometers

For convenient non-contact surface Temperature measurements

on areas hard to reach or unsafe to touch

400A True RMS Clamp Meters +

IR Thermometer

Experience the

PRODUCT DATASHEET

Specifications EX622 EX623

True RMS • •

Display counts 4000 4000

AC Current 0.01A to 400.0A 0.01A to 400.0A

DC Current — 0.01A to 400.0A

Basic Accuracy (ACA) 1.5% 1.5%

DC Voltage 0.1mV to 600V 0.1mV to 600V

AC Voltage 0.1mV to 600V 0.1mV to 600V

DC µA Current (DMM) 1µA to 400mA 1µA to 400mA

Resistance 0.1Ω to 40.00MΩ 0.1Ω to 40.00MΩ

Frequency 0.001Hz to 50.00kHz 0.001Hz to 50.00kHz

Capacitance 1nF to 10,000.0µF 1nF to 10,000.0µF

Temperature (IR) -58 to 518°F -58 to 518°F

(-50 to 270°C) (-50 to 270°C)

Temperature (Type K) -58 to 1832°F -58 to 1832°F

(-50 to 1000°C) (-50 to 1000°C)

Duty Cycle 0.1 to 99.9% 0.1 to 99.90%

Diode • •

Continuity • •

Dimensions 9x3.1x1.9" 9x3.1x1.9"

(229x80x49mm) (229x80x49mm)

Weight 10.7oz (303g) 10.7oz (303g)

Patented
