Ordering Information:

EX840 ..................1000A AC/DC True RMS Clamp/DMM+IR Thermometer

EX840-NISTL*......1000A AC/DC True RMS Clamp/DMM+IR Thermometer w/NIST Certificate

*NISTL is a Limited NIST: Product is certified to all functions except IR Thermometer

EX840 CAT IV Clamp Meter Features:

• Patented built-in non-contact IR Thermometer design with

laser pointer

• True RMS Current and Voltage measurements

• Peak hold captures inrush currents and Transients

• MultiMeter functions include AC/DC Voltage, Resistance,

Capacitance, Frequency, Diode, and Continuity

• 1.7" (43mm) jaw opening for conductors up to 750MCM

or two 500MCM

• 4000 count backlit display

• Features include Data Hold and Min/Max and Auto Power off

• Autoranging with manual range button

• Complete with CAT IV test leads, 9V battery, Type K

probe, pouch case, and Professional Test Lead Set

Professional Test Lead Features:

• 8-Piece Professional Test Lead set

• Two 42" (1m) PVC lead extensions with shrouded

banana plugs at both ends

• Two modular 4" (102mm) Heavy Duty test probe

handles with 0.16" (4mm) banana plug tip

• Two standard size, alligator clips with insulated rubber boot

• Two extra large, double-insulated, alligator clips with sharp

teeth for piercing insulated wire. Jaws open to 0.8" (20mm)

CAT IV 1000A Clamp Meter + IR Thermometer

Industrial Clamp-on multimeter with CAT IV-600V safety rating

Ideal for industrial applications, this full-size True RMS 1000A AC/DC Clamp features a built-in

Infared Thermometer and rugged double molded housing.

Specifications subject to change without notice.

www.extech.com

3/05/09 - R1

Patented

Built-in IR Thermometer with

laser pointer is an excellent

troubleshooter for locating hot

spots and overheating motors.

CAT IV -600V safety rating for

added protection and True RMS

feature gives you accurate readings

of non-sinusoidal waveforms.

Includes:

Pouch case to store the meter, temperature

probe, and test leads. The additional 8pc

set Professional Test Leads are packaged

separately.

Specifications Range Basic Accuracy

AC Current 0.1 to 1000A ±2.8%

DC Current 0.1 to 1000A ±2.8%

AC Voltage 0.1mV to 1000V ±1.5%

DC Voltage 0.1mV to 1000V ±2.8%

Resistance 0.1 to 40MΩ ±1.5%

Capacitance 0.001nF to 40,000μF ±3.0%

Frequency 0.001kHz to 4kHz ±1.5%

IR Temperature -58 to 518ºF (-50 to 270ºC) ±2.0% rdg or ±4ºF/±2ºC

Type K Temperature -4 to 1400ºF (-20 to 760ºC) ±(3%rdg+9°F/5ºC)

Continuity Yes

Inrush Yes

Diode Yes

Dimensions 10.6x4.3x2" (270x110x50mm)

Weight 13.6oz (386g)
