Introduction

Congratulations on your purchase of the Extech EX840 CAT IV True RMS 1000A Clamp Meter.

This meter measures AC/DC Voltage, AC/DC Current, Resistance, Capacitance, Frequency, Duty

Cycle, Diode Test, Continuity, Type k thermocouple thermometer plus Non-Contact IR Temperature.

Proper use and care of this meter will provide many years of reliable service.

Safety

International Safety Symbols

This symbol, adjacent to another symbol or terminal, indicates the user must refer to the

manual for further information.

This symbol, adjacent to a terminal, indicates that, under normal use, hazardous voltages

may be present

Double insulation

SAFETY NOTES

• Do not exceed the maximum allowable input range of any function.

• Do not apply voltage to meter when resistance function is selected.

• Set the function switch OFF when the meter is not in use.

• Remove the battery if meter is to be stored for longer than 60 days.

WARNINGS

• Set function switch to the appropriate position before measuring.

• When measuring volts do not switch to current/resistance modes.

• Do not measure current on a circuit whose voltage exceeds 600V.

• When changing ranges always disconnect the test leads from the circuit under test.

Function Maximum Input

A AC, ADC 1000A DC/AC

V DC, V AC 1000V DC/AC

Resistance, Capacitance, Frequency, Diode Test 250V DC/AC

Type K Temperature 60V DC, 24V AC
