1-5 Installing an Expansion Card

Read the following guidelines before you begin to install an expansion card:

• Make sure the motherboard supports the expansion card. Carefully read the manual that came

with your expansion card.

• Always turn off the computer and unplug the power cord from the power outlet before installing an

expansion card to prevent hardware damage.

Due to CPU limitations, read the following guidelines before installing the memory in Dual Channel mode.

1. Dual Channel mode cannot be enabled if only one memory module is installed.

2. When enabling Dual Channel mode with two or four memory modules, it is recommended that memory

of the same capacity, brand, speed, and chips be used.

Dual Channel Memory Congurations Table:

DDR4_4 DDR4_2 DDR4_3 DDR4_1

Two Modules

- - DS/SS - - DS/SS

DS/SS - - DS/SS - -

Four Modules DS/SS DS/SS DS/SS DS/SS

(SS=Single-Sided, DS=Double-Sided, "- -"=No Memory)

1-6 Setting up AMD CrossFire

™

/NVIDIA

SLI

™

Conguration

A. System Requirements

- Windows 10 64-bit operating system

- A CrossFire/SLI-supported motherboard with two or more PCI Express x16 slots and correct driver

- CrossFire/SLI-ready graphics cards of identical brand and chip and correct driver

- CrossFire

(Note)

/SLI bridge connectors

- A power supply with sufcient power is recommended (Refer to the manual of your graphics cards for the

power requirement)

B. Connecting the Graphics Cards

Step 1:

Observe the steps in "1-5 Installing an Expansion Card" and install CrossFire/SLI graphics cards on the PCIEX16

and PCIEX8 slots.

Step 2:

Insert the CrossFire

(Note)

/SLI bridge connectors in the CrossFire/SLI gold edge connectors on top of the cards.

Step 3:

Plug the display cable into the graphics card on the PCIEX16 slot.

C.ConguringtheGraphicsCardDriver

C-1. To Enable CrossFire Function

After installing the graphics card driver in the operating system, go to the AMD RADEON SETTINGS screen.

Browse to Gaming\Global Settings and ensure AMD CrossFire is set to On.

C-2. To Enable SLI Function

After installing the graphics card driver in the operating system, go to the NVIDIA Control Panel. Browse to the

CongureSLI,Surround,PhysX screen and ensure Maximize 3D performance is enabled.

Procedure and driver screen for enabling CrossFire/SLI technology may differ by graphics cards

and driver version. Refer to the manual that came with your graphics cards for more information

about enabling CrossFire/SLI technology.

(Note) The bridge connector(s) may be needed or not depending on your graphics cards.
