TECHNICAL SPECIFICATIONS
EWAQ F-XS
430
450
520
610
680
400
MODEL
Capacity - Cooling (1) kW 672 607 528 428 403 457
Capacity control - Type
---
Step
Step
Step
Step
Step
Step
Capacity control - Minimum capacity % 17.0 14.0 17.0 20.0 21.0 25.0
Unit power input - Cooling (1)
kW
219
198
170
137
130
146
EER (1)
---
3.07
3.07
3.10
3.12
3.10
3.12
ESEER --- 4.14 4.24 4.29 4.26 4.22 4.22
IPLV
---
4.57
4.76
4.88
4.64
4.69
4.59
CASING
Colour (2)
---
IW
IW
IW
IW
IW
IW
Material (2) --- GPSS GPSS GPSS GPSS GPSS GPSS
DIMENSIONS
Height
mm
2221
2221
2221
2221
2221
2221
Width mm 2258 2258 2258 2258 2258 2258
Length
mm
5910
5010
5010
4110
4110
4110
WEIGHT
Unit Weight
kg
4054
3667
3569
2845
2744
2861
Operating Weight kg 4115 3727 3615 2891 2784 2907
WATER HEAT EXCHANGER
Type (3)
---
PHE
PHE
PHE
PHE
PHE
PHE
Water Volume l 60 60 46 46 40 46
Nominal water flow rate - Cooling
l/s
32.2
29.0
25.3
20.5
19.3
21.8
Nominal Water pressure drop - Cooling kPa 55 44 41 29 31 30
Insulation material (4)
CC
CC
CC
CC
CC
CC
AIR HEAT EXCHANGER
Type (5) --- HFP HFP HFP HFP HFP HFP
FAN
Type (6) --- DPT DPT DPT DPT DPT DPT
Drive (7)
---
DOL
DOL
DOL
DOL
DOL
DOL
Diameter mm 800 800 800 800 800 800
Nominal air flow
l/s
60489
50408
50408
40326
42296
40326
Quantity
No.
12
10
10
8
8
8
Speed rpm 900 900 900 900 900 900
Motor input
kW
21.0
17.5
17.5
14.0
14.0
14.0
COMPRESSOR
Type
---
Scroll
Scroll
Scroll
Scroll
Scroll
Scroll
Oil charge l 38 38 38 25 25 25
Quantity No. 6 6 6 4 4 4
SOUND LEVEL
Sound Power - Cooling dB(A) 100 99 98 98 97 98
Sound Pressure - Cooling (8)
dB(A)
79
79
78
78
78
79
REFRIGERANT CIRCUIT
Refrigerant type
---
R410A
R410A
R410A
R410A
R410A
R410A
Refrigerant charge kg 46 40 40 35 35 35
N. of circuits No. 2 2 2 2 2 2
PIPING CONNECTIONS
Evaporator water inlet/outlet 3" 3" 3" 3" 3" 3"
Fluid: Water
(1) Cooling capacity, unit power input in cooling and EER are based on the following conditions: evaporator 12.0/7.0°C; ambient 35.0°C, unit at full load
operation;
(2) IW: Ivory White; GPSS: Galvanized and Painted Steel Sheet; (3) PHE: Plate Heat Exchanger --- S&T: Single Pass Shell & Tube
(4) CC: Closed Cell; (5) HFP: High efficiency fin and tube type with integral subcooler
(6) DPT: Direct Propeller Type; (7) DOL: Direct On Line - VFD: Inverter - BRS: Brushless
(8) The values are according to ISO 3744 and are referred to: evaporator 12/7°C, ambient 35°C, full load operation.
