- 4 -
GA-B250M-EVO Motherboard Layout
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 GA-B250M-EVO motherboard 5 SATA cables
5 Motherboard driver disk 5 I/O Shield
5 User's Manual
KB_MS
CPU_FAN
SYS_FAN
LGA1151
ATX
GA-B250M-EVO
F_AUDIO
AUDIO
BAT
ATX_12V_2X4
Intel
®
B250
R_USB30_2
CODEC
CLR_CMOS
BIOS
USB_LAN
PCIEX16
PCIEX1
iTE
®
Super I/O
Realtek
®
GbE LAN
F_USB1F_USB2
F_PANEL
SPDIF_O
F_USB30
DVI
SATA3
5 4
3 2
DDR4_2
DDR4_1
R_USB30_1
M2P_32G
80 60 42
COM
