Resistance Test Report
10/10/2017
Operator
Chauvin-Arnoux
CA
190, rue Championnet
PARIS, France 75018
Test Site
,
Model: Micro-Ohmmeter Model 6250, ID: 0502OO44-0024 A, Firmware:
Comments
Database File Name: Micro-Ohmmeter-0502OO44-0024 A-20171010-Object 1.dvb
6250 Resistance Test Report (Micro-Ohmmeter-0502OO44-0024 A-20171010-Object 1) - Cover Sheet, 1 of 2
Index
Name
Value
Units
1
Object 1, Test 1
0,077
Ohm
2
Object 1, Test 2
0,077
Ohm
Channel Name Object 1, Test 1
Start Date 10/10/2017
Start Time 11:57:11
Instrument Model 6250
Test Number 1
Measurement Type Inductive
Metal Type Copper
Measurement Range 250 milli-Ohm
Metal Coefficient 3,93
Tamb 23,90°C
Tref 27,00°C
Resistance @ (Tamb) 77,10 mȍ
Resistance @ (Tref) 77,96 mȍ
6250 Resistance Test Report (Micro-Ohmmeter-0502OO44-0024 A-20171010-Object 1) - Test Summary, 2 of 2
With its intuitive use, the C.A "high-
performance" micro-ohmmeter is ideal for
measuring very low resistance values with
very high accuracy: ..
INTERFACE for
connection to a PC
Choice of measurement mode /
Selection of the metal for temperature
compensation calculation
Activation / deactivation
of the temperature
compensation function
4 safety
terminals
Wide measurement
range with 7 calibres
accessible using the
rotary switch
Large backlit
LCD screen with
double display
Storage of up to
1,500measurements /
rereading of data
software platform for
data processing
The MOT module of DataView® can be
used to:
Configure instruments connected
to a PC
Recover the measurement data
stored inthe instrument
Back up the measurement files
Open saved files
Process the data and create reports
Export the data into an Excel
spreadsheet
Export in .pdf format
Manage the database
Kelvin 10 A clamps
Two models of retractable 10 A Kelvin test
probes are available:
test probes with rotation: these
can pivot for better contact with
the part to be measured
“pistol-type”
test probes
