CHAUVIN ARNOUX CA-6255 [4/4] Accessories
![CHAUVIN ARNOUX CA-6255 [4/4] Accessories](/views2/1668744/page4/bg4.png)
- Ed. - VS - / - Non-contractual document. Specifications subject to modifications linked technological developments.
State at delivery
Delivered with a bag containing:
• set of cables m long terminated by Kelvin clamps
• Euro mains power lead m long
• user’s manuals ( per language)
• simplified user’s manuals ( per language)
• MOT (Micro-Ohmmeter Transfer) data transfer software
on CD-ROM
• x RS communication cable
Reference to order
C.A
........................................................
P
4-wire measurement method
Calibre 5.0000 m 25.000 m 250.00 m 2500.0 m 25.000 250.00 2500.0
Resolution 0.1 1 10 0.1 m 1 m 10 m 100 m
1-year accuracy
0.05 %
+1
0.05 %
+ 3
0.05 %
+30
0.05 %
+0,3m
0.05 %
+3m
0.05 %
+30m
0.05 %
+300m
Measurement current 10 A 10 A 10 A 1 A 100 mA 10 mA 1 mA
Voltage drop 50 mV 250 mV 2,500 mV 2,500 mV 2,500 mV 2,500 mV 2,500 mV
Measurement modes Inductive, non-inductive, non-inductive with automatic trigger
Temperature compensation By temperature sensor or manual
Data storage 1,500 measurements
Communication output RS 232 link
Power supply NiMH rechargeable battery
Dimensions / Weight 270 x 250 x 180 mm / approx. 4 kg
Technical specifications
Accessories
Double test probes and Kelvin clamps for micro-ohmmeters Reference
10 A Kelvin clamps
(set of 2)
• L = 3 m
Spade lug P01101794
Double 10 A “pistol”
test probe (set of 2)
• L = 3.15 m
• Ø 2 mm test probes
• Test-probe spacing: 3.5 mm
Spade lug
and 4 mm
banana
P01103065
Double 10 A pivoting
test probe (set of 2)
• L = 3.15 m
• Ø 3 mm test probes
• Travel of probes: 10 mm
Spade lug
and 4 mm
banana
P01103063
1 A Mini Kelvin clamps
(set of 2)
Spade lug P01101783
Double 1 A test probe
(set of 2)
• L = 2.85 m
Spade lug
and 4 mm
banana
P01102056
Temperature
Pt 100 probe P01102013
Middle East
Chauvin Arnoux Middle East
P.O. BOX 60-154
1241 2020 JAL EL DIB - LEBANON
Tel: +961 1 890 425
Fax: +961 1 890 424
camie@chauvin-arnoux.com
www.chauvin-arnoux.com
UNITED KINGDOM
Chauvin Arnoux Ltd
Unit 1 Nelson Ct, Flagship Sq, Shaw Cross Business Pk
Dewsbury, West Yorkshire - WF12 7TH
Tel: +44 1924 460 494
Fax: +44 1924 455 328
info@chauvin-arnoux.co.uk
www.chauvin-arnoux.com
FRANCE
Chauvin Arnoux
190, rue Championnet
75876 PARIS Cedex 18
Tel: +33 1 44 85 44 38
Fax: +33 1 46 27 95 59
export@chauvin-arnoux.fr
www.chauvin-arnoux.com
