- 13 -

Hardware Installation

Bundled

Software

 Norton

InternetSecurity(OEMversion)

 Intel

SmartResponseTechnology

Operating

System

 Support for Windows 10/8.1 64-bit

 Support for Windows 7 32-bit/64-bit

* Pleasedownloadthe"WindowsUSBInstallationTool"fromGIGABYTE'swebsite

and install it before installing Windows 7.

Form Factor  ATX Form Factor; 30.5cm x 24.4cm

* GIGABYTEreservestherighttomakeanychangestotheproductspecicationsandproduct-relatedinformationwithout

prior notice.

Please visit GIGABYTE's website for support lists of CPU, memory modules, SSDs, and M.2

devices.

Please visit the Support\Utility List page on GIGABYTE's website to download the latest

version of apps.
