- 11 -

Hardware Installation

Storage Interface - Support for RAID 0, RAID 1, RAID 5, and RAID 10

* OnlyAHCImodeissupportedwhenanM.2PCIeSSDoraSATAExpressdeviceis

installed.

(M2_10G,SATAExpress,andSATA34/5connectorscanonlybeusedoneata

time. The SATA3 4/5 connectors will become unavailable when an M.2 SSD is

installedintheM2_10Gconnector.)

 Chipset:

- 4xSATA6Gb/sconnectors(sSATA30~3),supportingIDEandAHCI

modes only

(AnoperatingsysteminstalledontheSATA30~5portscannotbeusedonthe

sSATA30~3ports.)

USB  Chipset:

- 4xUSB3.0/2.0ports(availablethroughtheinternalUSBheaders)

- 6xUSB2.0/1.1ports(2portsonthebackpanel,4portsavailablethrough

theinternalUSBheaders)

 Chipset + 2 Renesas

uPD720210 USB 3.0 Hubs:

- 8 x USB 3.0/2.0 ports on the back panel

Internal

Connectors

 1 x 24-pin ATX main power connector

 1 x 8-pin ATX 12V power connector

 1 x PCIe power connector

 1 x I/O shield audio LED power connector

 1 x heatsink LED power connector

 1 x SATA Express connector

 10 x SATA 6Gb/s connectors

 1 x M.2 Socket 3 connector

 1 x CPU fan header

 1xwatercoolingfanheader(CPU_OPT)

 3 x system fan headers

 1 x front panel header

 1 x front panel audio header

 2 x USB 3.0/2.0 headers

 2 x USB 2.0/1.1 headers

 1 x Thunderbolt add-in card connector

 1 x Clear CMOS jumper

 1 x power button

 1 x reset button

 1 x Clear CMOS button

 1 x Direct to BIOS button

 1 x audio gain control switch

 Voltage Measurement Points

 2 x BIOS switches

Back Panel

Connectors

 1 x PS/2 keyboard/mouse port

 1 x CPU overclocking button

 1 x Fast Boot button

 1 x Clear CMOS button

 8 x USB 3.0/2.0 ports

 2 x USB 2.0/1.1 ports
