- 31 -
Hardware Installation
9) SATA_EXPRESS (SATA Express Connector)
The SATA Express connector supports a single SATA Express device.
F_USB30
F_U
B_
F_ F_
_
B
BS_
B
SB_
B
_S
S_
_
B
_U
_
B
S
123
123
123
123
1
1
1
1
BSS
S
_S
SSU
1 2 3
S3
BSSS
U
__ 3
F_USB3F
S _
S _
S _
SF
B_
F
_0
S
S
_0F
_F
M2_10G, SATA Express, and SATA3 4/5 connectors can only be used one at a time. The SATA3 4/5
connectors will become unavailable when an M.2 SSD is installed.
8) LED_CON2 (Heatsink LED Power Connector)
The power connector provides power to the LEDs on the Chipset heatsink.
Pin No. Denition
1 VCC
2 GND
1
