Gigabyte GA-X99-Gaming G1 WIFI (rev. 1.0) [6/136] Box contents

- 6 -

Box Contents

5 GA-X99-Gaming G1 WIFI motherboard

5 Motherboard driver disk

5 Wireless module driver disk

5 User's Manual

5 Quick Installation Guide

5 Six SATA cables

5 I/O Shield

5 One 2-Way SLI bridge connector

5 Two3-WaySLIbridgeconnectors(GC-3SLI-X99andGC-3SLI)

5 One 4-Way SLI bridge connector

5 One 2-Way CrossFire bridge connector

5 One antenna

5 One1to3powercable(2x4ATX12V)

Optional Items

 2-portUSB2.0bracket(PartNo.12CR1-1UB030-6*R)

 eSATAbracket(PartNo.12CF1-3SATPW-4*R)

 3.5"FrontPanelwith2USB3.0/2.0ports(PartNo.12CR1-FPX582-2*R)

The box contents above are for reference only and the actual items shall depend on the product package you obtain.

The box contents are subject to change without notice.
