1-7 Back Panel Connectors

PS/2 Keyboard and PS/2 Mouse Port

Usetheupperport(green)toconnectaPS/2mouseandthelowerport(purple)toconnectaPS/2keyboard.

D-Sub Port

TheD-Subportsupportsa15-pinD-Subconnectorandsupportsamaximumresolutionof1920x1200@60Hz

(theactualresolutionssupporteddependonthemonitorbeingused).Connectamonitorthatsupports

D-Sub connection to this port.

DVI-D Port

(Note)

TheDVI-DportconformstotheDVI-Dspecicationandsupportsamaximumresolutionof1920x1200@60Hz

(theactualresolutionssupporteddependonthemonitorbeingused).Connectamonitorthatsupports

DVI-D connection to this port.

USB 3.0/2.0 Port

TheUSB3.0portsupportstheUSB3.0specicationandiscompatibletotheUSB2.0/1.1specication.

UsethisportforUSBdevicessuchasaUSBkeyboard/mouse,USBprinter,USBashdriveandetc.

HDMI Port

The HDMI port is HDCP compliant and supports Dolby True HD and DTS HD

MasterAudioformats.Italsosupportsupto192KHz/24bit8-channelLPCMaudio

output. You can use this port to connect your HDMI-supported monitor. The maximum supported resolution

is4096x2160@24Hzor2560x1600@60Hz,buttheactualresolutionssupportedaredependentonthe

monitor being used.

(Note) TheDVI-DportdoesnotsupportD-Subconnectionbyadapter.

Triple-DisplayCongurationsfortheOnboardGraphics:

 Triple-displaycongurationsaresupportedafteryouinstallmotherboarddriversinOS.Onlydual-display

congurationsaresupportedduringtheBIOSSetuporPOSTprocess.

After installing the HDMI device, make sure to set the default sound playback device to HDMI.

(Theitemnamemaydifferdependingonyouroperatingsystem.Thescreenshotbelowisfrom

Windows8.1.)

In Windows 8.1, select Apps>Control Panel>Hardware and

Sound>Sound>Playback,setIntel(R)DisplayAudiotothe

default playback device.
