1-2 ProductSpecications
CPU Support for Intel
®
Core
™
i7 processors/Intel
®
Core
™
i5 processors/
Intel
®
Core
™
i3 processors/Intel
®
Pentium
®
processors/Intel
®
Celeron
®
processors
in the LGA1150 package
(GotoGIGABYTE'swebsiteforthelatestCPUsupportlist.)
L3 cache varies with CPU
Chipset Intel
®
Z97 Express Chipset
Memory 2 x DDR3 DIMM sockets supporting up to 16 GB of system memory
* DuetoaWindows32-bitoperatingsystemlimitation,whenmorethan4GBofphysical
memoryisinstalled,theactualmemorysizedisplayedwillbelessthanthesizeof
the physical memory installed.
Dual channel memory architecture
SupportforDDR31600/1333MHzmemorymodules
Support for non-ECC memory modules
SupportforExtremeMemoryProle(XMP)memorymodules
(GotoGIGABYTE'swebsiteforthelatestsupportedmemoryspeedsandmemory
modules.)
Onboard
Graphics
Integrated Graphics Processor:
- 1 x DVI-I port, supporting a maximum resolution of 1920x1200@60Hz
- 1xHDMIport,supportingamaximumresolutionof4096x2160@24Hzor
2560x1600@60Hz
* SupportforHDMI1.4aversion.
- 1xDisplayPort,supportingamaximumresolutionof4096x2160@24Hzor
3840x2160@60Hz
* SupportforDisplayPort1.2version.
- Support for up to 3 displays at the same time
- Maximum shared memory of 1 GB
Audio Realtek
®
ALC1150 codec
SupportforSoundBlasterX-FiMB3
HighDenitionAudio
2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN Qualcomm
®
AtherosKillerE2201LANchip(10/100/1000Mbit)
Wireless
Communication
module
Wi-Fi802.11a/b/g/n/ac,supporting2.4/5GHzDual-Band
Bluetooth 4.0, 3.0+HS, 2.1+EDR
Support for 11ac wireless standard and up to 867 Mbps data rate
* Actualdataratemayvarydependingonenvironmentandequipment.
Expansion Slots 1 x PCI Express x16 slot, running at x16
(ThePCIEX16slotconformstoPCIExpress3.0standard.)
1 x mini-PCI Express slot for the wireless communication module
Storage Interface Chipset:
- 5xSATA6Gb/sconnectors(SATA30/1/2/3/4)
- 1 x eSATA 6Gb/s connector on the back panel
* Actualtransferrateisdependentonthedevicebeingconnected.
- Support for RAID 0, RAID 1, RAID 5, and RAID 10
