15
GB
Connecting the drain hose
Connect the drain hose,
without bending it, to a
drain duct or a wall drain
situated between 65 and
100 cm from the floor;
alternatively, place it
over the edge of a
basin, sink or tub,
fastening the duct
supplied to the tap (see
figure). The free end of
the hose should not be
underwater.
We advise against the use of hose extensions; if it is
absolutely necessary, the extension must have the
same diameter as the original hose and must not
exceed 150 cm in length.
Electrical connections
Before plugging the appliance into the electricity
socket, make sure that:
the socket is earthed and complies with all
applicable laws;
the socket is able to withstand the maximum
power load of the appliance as indicated in the
Technical data table (see opposite);
the power supply voltage falls within the values
indicated in the Technical data table (see opposite);
the socket is compatible with the plug of the
washing machine. If this is not the case, replace the
socket or the plug.
The washing machine must not be installed
outdoors, even in covered areas. It is extremely
dangerous to leave the appliance exposed to rain,
storms and other weather conditions.
When the washing machine has been installed, the
electricity socket must remain within easy reach.
Do not use extension cords or multiple sockets.
65 - 100 cm
The cable should not be bent or compressed.
The power supply cable must only be replaced by
authorised technicians.
Warning! The company shall not be held responsible
in the event that these standards are not observed.
The first wash cycle
Once the appliance has been installed, and before you
use it for the first time, run a wash cycle with
detergent and no laundry, using wash cycle number 2.
Technical data
Model
PWE 7108 S
Dimensions
width 59.5 cm
height 85 cm
depth 55 cm
Capacity
between 1 and 7 kg
Electrical
connections
please refer to the technical data
plate applied to the machine
Water connections
maximum pressure 1 MPa (10 bar
)
minimum pressure 0.05 MPa
(0.5 bar)
drum capacity 52 litres
Spin speed
up to 1000 rpm
Test wash cycles
in compliance with
regulation EN
60456
wash cycle 2; temperature 60°C;
performed with a 7 kg load.
This appliance conforms to the
following European Community
directives:
- 89/336/EEC dated 03.05.89
(Electromagnetic Compatibility)
and subsequent amendments
- 2006/95/EC – 2006/95/EC (Low
Voltage)
