Gigabyte GA-J3355N-D2P (rev. 1.0) [10/31] 6 internal connectors
![Gigabyte GA-J3355N-D2P (rev. 1.0) [10/31] 6 internal connectors](/views2/1669120/page10/bga.png)
- 10 -
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1-6 Internal Connectors
1) ATX_12V
2) ATX
3) CPU_FAN
4) SYS_FAN
5) SATA3 0/1
6) F_PANEL
7) F_AUDIO
8) BAT
9) F_USB1/F_USB2
10) COMA
11) TPM
12) SPEAKER
13) CLR_CMOS
14) CI
15) BIOS_SET
16) SPDIF_O
1 12
5
16
7
9
15
8
3
2
4
6
10
11
13 14
