- 10 -
Hardware Installation
1-2 ProductSpecications
CPU SocketTR4:
- AMD Ryzen
™
Threadripper
™
processor
(Go to GIGABYTE's website for the latest CPU support list.)
Chipset AMD X399
Memory 8 x DDR4 DIMM sockets supporting up to 128 GB of system memory
Quad channel memory architecture
Support for DDR4 2667/2400/2133 MHz memory modules
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Audio Realtek
®
ALC1220 codec
Support for Sound BlasterX 720°
High Denition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN 2 x Intel
®
GbE LAN chips (10/100/1000 Mbit)
Wireless
Communication
Module
Wi-Fi 802.11 a/b/g/n/ac, supporting 2.4/5 GHz Dual-Band
BLUETOOTH 4.2, 4.1, BLE, 4.0, 3.0, 2.1+EDR
Support for 11ac wireless standard and up to 867 Mbps data rate
* Actual data rate may vary depending on environment and equipment.
Expansion Slots 2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2)
2 x PCI Express x16 slots, running at x8 (PCIEX8_1, PCIEX8_2)
(The PCIEX16 and PCIEX8 slots conform to PCI Express 3.0 standard.)
1 x PCI Express x16 slot, running at x4 (PCIEX4)
(The PCIEX4 slot conforms to PCI Express 2.0 standard.)
Multi-Graphics
Technology
Support for AMD Quad-GPU CrossFire
™
and 4-Way/3-Way/2-Way AMD
CrossFire
™
technologies
Support for NVIDIA
®
Quad-GPU SLI
™
and 4-Way/3-Way/2-Way NVIDIA
®
SLI
™
technologies
Storage Interface 2 x M.2 connectors (Socket 3, M key, type 2260/2280/22110 SATA and PCIe x4/
x2 SSD support) (M2M_32G)(M2Q_32G)
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2
SSD support) (M2P_32G)
8 x SATA 6Gb/s connectors
Support for RAID 0, RAID 1, and RAID 10
USB CPU:
- 8 x USB 3.1 Gen 1 ports on the back panel
Chipset:
- 1 x USB Type-C
™
port on the back panel, with USB 3.1 Gen 2 support
- 1 x USB 3.1 Gen 2 Type-A port (red) on the back panel
- 1 x USB Type-C
™
port with USB 3.1 Gen 1 support, available through the
internal USB header
