1-7 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V
2) ATX
3) CPU_FAN
4) SYS_FAN1/SYS_FAN2
5) SATA3 0/1/2/3
6) M2A_CPU
7) SPDIF_O
8) F_PANEL
9) F_ AUDIO
10) F_USB30
11) F_USB1/F_USB2
12) COMB
13) LPT
14) TPM
15) BAT
16) CLR_CMOS
4
2
3
139
8
5
12
1
6
16
11 10
4
14
7
15
- 12 -
